Ingersoll Rand Non-Programmable Cordless Clutch Screwdriver | QCN2P04Q4 | 20 Voltage | 1 - 4 (Nm) Torque Range

Ingersoll Rand QCN2P04Q4 Non-Programmable Cordless Clutch Screwdriver provides precision fastening with the flexibility of cordless operation. Part of the QC Series, this 20V pistol-grip screwdriver features an adjustable 1–4 Nm torque range, allowing operators to select the appropriate tightening torque for smaller threaded fasteners used in manufacturing and component assembly. Its 1/4" hex drive accommodates matching screwdriver bits, while the 350–1,160 RPM speed range supports controlled fastener engagement and efficient screw rundown. The auto shut-off clutch automatically stops the fastening operation when the selected torque is reached, helping maintain repeatable tightening results across production cycles.

Powered by the Ingersoll Rand IQV20 20V battery platform, the QCN2P04Q4 combines mechanical clutch adjustment with immediate visual fastening feedback. Its proven clutch design delivers Cmk > 1.67 with ±10% accuracy, supporting consistent torque output under manufacturer-specified conditions. Cmk is a machine capability index used to evaluate the repeatability of a fastening process. A configurable 360° LED ring light displays red for NOK (not OK) tightening, green for OK tightening, and white for work-area illumination. The Cycle Status Indicator provides additional PASS/FAIL feedback, allowing operators to identify fastening results quickly. Equipped with a brushless DC motor, locking clutch adjustment door, and dual-speed non-contact trigger, the screwdriver weighs 2.3 lbs without battery and is suited to repetitive production assembly operations.

Type: Non-Programmable Cordless Clutch Screwdriver | Model: QCN2P04Q4 | Series: QC Series | Tool Configuration: Pistol | Voltage: 20V | Battery Platform: IQV20 | Drive: 1/4" Hex | Torque Range: 1–4 Nm | Speed: 350–1,160 RPM | Motor: Brushless DC | Clutch: Auto Shut-Off | Torque Accuracy: ±10% | Weight Without Battery: 2.3 lbs | Length Without Battery: 210 mm | Height Without Battery: 208.6 mm | Setup: Non-Programmable

Features:

• Auto shut-off clutch delivers consistent tightening performance, with Cmk > 1.67 and ±10% accuracy under manufacturer-specified conditions.
• Adjustable clutch allows operators to establish tightening torque according to the fastening application.
• Lockable, tamper-proof clutch adjustment door helps prevent unintended torque-setting changes during production.
• Non-programmable setup simplifies fastening operations without requiring electronic program configuration.
• Brushless DC motor supports enhanced durability in repetitive assembly environments.
• Dual-speed, non-contact trigger is designed to withstand more than one million operating cycles.
• Configurable 360° LED ring light displays red for NOK tightening, green for OK tightening, and white for task illumination.
• Cycle Status Indicator provides PASS/FAIL feedback to help operators verify fastening results.
• Lightweight, balanced pistol-grip configuration supports tool handling during repetitive fastening operations.
• QC Series clutch tools are designed to last more than 500,000 cycles in demanding production environments.
• IQV20 battery platform compatibility supports cordless operation using manufacturer-listed BL20212 and BL2022 batteries and BC1121 charger.

Applications:

• Automotive component assembly – tightening smaller threaded fasteners on interior components, brackets, and mechanical assemblies requiring controlled torque.
• Appliance manufacturing – securing equipment covers, housings, and mounting hardware during repetitive production operations.
• Electrical equipment assembly – fastening panels, enclosures, and mechanical components where consistent tightening is required.
• Industrial production lines – performing repeated screwdriving tasks with automatic clutch shut-off and visual tightening confirmation.
• Light machinery assembly – installing threaded components within the specified torque range while maintaining consistent fastening procedures.

FAQs:

• Q: What is the torque range of the Ingersoll Rand QCN2P04Q4?
  A: The QCN2P04Q4 provides an adjustable torque range of 1–4 Nm. Its auto shut-off clutch stops the fastening operation when the selected torque is reached, helping deliver consistent tightening during repeated assembly cycles.
• Q: What is the difference between the QCN2P04Q4 and QCN2P02Q4 cordless screwdrivers?
  A: The primary difference is their torque range. The QCN2P04Q4 operates from 1–4 Nm, while the QCN2P02Q4 operates from 0.5–2 Nm. Both models feature pistol-grip configurations, 1/4" hex drives, and 350–1,160 RPM speed ranges. Select the model that matches the required fastening torque.
• Q: Does the QCN2P04Q4 require programming software?
  A: No. The QCN2P04Q4 is a non-programmable clutch screwdriver that uses mechanical torque adjustment. Its locking clutch door helps protect the selected setting during production operations.
• Q: How does the screwdriver indicate successful tightening?
  A: The configurable LED ring light displays green for OK tightening and red for NOK tightening. A separate Cycle Status Indicator provides PASS/FAIL feedback, helping operators recognize fastening results without additional programming.
• Q: Which batteries and chargers are compatible with the QCN2P04Q4?
  A: The screwdriver uses the Ingersoll Rand IQV20 battery platform. The manufacturer lists BL20212 and BL2022 compatible batteries and the BC1121 charger. Ingersoll Rand also offers the separate QCN2P04Q4-K2 kit, which includes the 4 Nm pistol screwdriver, two BL2012 2.5 Ah batteries, and a charger.
