Ingersoll Rand ML500KS-2C27-C60U MLK Series Air Chain Hoist | 1/2 Ton Capacity | 27 ft Lift | 60 ft Drop | Steel Snap Hook | Pendent Control

Product images may not be an exact representation of the actual product. Please check the description below for technical specifications.

Ingersoll Rand

Ingersoll Rand ML500KS-2C27-C60U MLK Series Air Chain Hoist | 1/2 Ton Capacity | 27 ft Lift | 60 ft Drop | Steel Snap Hook | Pendent Control

List Price: $9,250.00
$8,159.12
(You save $1,090.88 )
Availability:
Available To Order From Supplier
SKU:
ML500KS-2C27-C60U
Shipping:
Calculated at Checkout
Weight:
60.0000 LBS
Condition:
New
Adding to cart… The item has been added
Description

Designed for dependable overhead lifting in manufacturing, maintenance, assembly, and material handling applications, the Ingersoll Rand ML500KS-2C27-C60U Air Chain Hoist combines a 1/2 Ton (1,100 lb / 500 kg) capacity with a 27 ft lift and an extended 60 ft pendent drop for applications requiring remote hoist operation from floor level. Part of the MLK Series, this pneumatic chain hoist features a six-vane air motor engineered for continuous 100% duty-cycle operation, delivering reliable lifting performance throughout demanding industrial shifts. The responsive 2-button pendent control enables smooth and accurate load positioning, while the steel snap hook with safety latch provides secure load engagement.

Engineered for reliable industrial service, the ML500KS-2C27-C60U features a spring-engaged, air-release non-asbestos disc brake that automatically secures suspended loads whenever the controls are released. Upper and lower limit stops help prevent excessive chain travel, while the compact hook-mounted configuration minimizes installation headroom requirements. An integrated fabric chain container keeps excess load chain organized during operation, making this hoist especially suitable for elevated installations with extended lifting heights.

Type: Air Chain Hoist | Series: MLK Series | Model: ML500KS-2C27-C60U | Capacity: 1/2 Ton (1,100 lb / 500 kg) | Lift: 27 ft | Pendent Drop: 60 ft | Control Type: 2-Button Pendent Control | Top Suspension: Top Hook | Bottom Hook: Steel Snap Hook with Safety Latch | Chain Container: Fabric Chain Container | Chain Falls: 1 | Load Chain Size: 4 × 12 mm | Air Inlet: 1/4 in. NPT | Operating Pressure: 70–100 PSI | Duty Cycle: 100%

Features:

  • Six-vane air motor delivers continuous 100% duty cycle operation.
  • Spring-engaged, air-release non-asbestos disc brake securely holds suspended loads.
  • Responsive 2-button pendent control enables smooth and accurate lifting and lowering.
  • Extended 60 ft control drop allows convenient operation from lower working levels.
  • Upper and lower limit stops help prevent excessive chain travel during operation.
  • Steel snap hook with integrated safety latch provides dependable load attachment.
  • Fabric chain container stores excess load chain to improve workplace organization.
  • Single-fall load chain configuration supports the rated 1/2 ton lifting capacity.
  • Meets ASME B30.16, ASME HST-5 Duty Rating A5, and FEM/ISO Classification 1Am/M4.

Applications:

  • High-bay manufacturing facilities requiring long pendant reach.
  • Maintenance operations servicing elevated machinery and equipment.
  • Assembly lines with overhead lifting systems.
  • Industrial fabrication facilities handling suspended components.
  • General material handling applications utilizing compressed air-powered lifting equipment.

FAQs:

  • Q: What is the lifting capacity of this hoist?
    A: The ML500KS-2C27-C60U is rated to lift up to 1/2 ton (1,100 lb / 500 kg).
  • Q: How many chain falls does this model use?
    A: This ML500KS model utilizes a single-fall (1-fall) load chain configuration designed for its rated 1/2 ton capacity.
  • Q: Does this model include a chain container?
    A: Yes. This configuration includes a fabric chain container to keep excess load chain safely contained during operation.
  • Q: Why is the pendent drop longer than the lift?
    A: The 60 ft control drop allows operators to control the hoist from floor level or another convenient location when the hoist is installed at significant height.
  • Q: Is this hoist suitable for continuous-duty operation?
    A: Yes. The six-vane pneumatic motor is designed for a continuous 100% duty cycle in demanding industrial applications.



industrial-tools-parts-breakdown.pngLooking for more information about Ingersoll Rand Air Hoist? Click here to view the Catalog.

Need more feet of chain or a longer pendant hose? How about a motorized trolley? Give us a call at 1-800-608-5210 or email info@intlairtool.com. We can help!

Specifications
Type:
Air Chain Hoist
Series:
MLK Series
Capacity (tons):
1/2
Capacity (lbs):
1100
Lift (ft.):
27
Drop (ft.):
60
Control:
Pendent Control
Top Suspension:
Swivel Top Hook
Bottom Suspension:
Steel Snap Hook
Chain Falls:
1
Hook Mount Headroom (in.):
18
Trolley Mount Headroom (in.):
18
Lifting Speed Rated Load (ft/min):
22
Lifting Speed Rated Load (m/min):
6.7
Lifting Speed No Load (ft/min):
44
Lifting Speed No Load (m/min):
13.4
Lowering Speed Rated Load (ft/min):
66
Lowering Speed Rated Load (m/min):
20.1
Lowering Speed No Load (ft/min):
32
Lowering Speed No Load (m/min):
9.8
Chain Size:
6.4 x 19.5
Warranty Information
One year warranty against manufacturers defects.
