Ingersoll Rand ELK50-1NS12-1PHP-14-12-A2CF15 ELK Series Electric Chain Hoist | 1/2 Ton Capacity | 14 ft Lift | 12 ft Drop | Plain Trolley | Pendent Control

Ingersoll Rand ELK50-1NS12-1PHP-14-12-A2CF15 ELK Series Electric Chain Hoist is designed to provide dependable overhead lifting for manufacturing, maintenance, and material handling applications requiring a 1/2 Ton (1,100 lbs) lifting capacity. Featuring a 14 ft lift, 12 ft pendent drop, plain trolley, and pendent control, this electric chain hoist delivers smooth load handling with manual horizontal travel for accurate positioning in industrial environments.

Built on the ELK50-1NS50 1 ph platform, this single-phase electric chain hoist utilizes a single-fall load chain configuration for efficient lifting performance. According to the Ingersoll Rand ELK Series catalog, the base model provides a 16 ft/min (5 m/min) lifting speed, H4 (2m) duty rating, and a compact 19.2 in (488 mm) headroom. The manually operated plain trolley allows smooth movement along compatible beam systems, making this hoist well suited for production facilities, warehouses, fabrication shops, and maintenance operations.

Type: Electric Chain Hoist | Series: ELK Series | Model: ELK50-1NS12-1PHP-14-12-A2CF15 | SKU: 47785777001 | Capacity: 1/2 Ton (1,100 lbs) | Power Supply: Single Phase 115/230V | Lift: 14 ft | Pendent Drop: 12 ft | Suspension: Plain Trolley | Control Type: Pendent Control | Lifting Speed: 16 ft/min (5 m/min) | Duty Rating: H4 (2m) | Falls: 1 | Headroom: 19.2 in (488 mm) | Body Weight: 57.3 lbs (26 kg) | Chain Weight: 0.46 lb/ft (0.69 kg/m)

Features:

• Rated lifting capacity of 1/2 ton (1,100 lbs) for industrial material handling applications.
• Single-phase 115/230V electric operation for facilities without three-phase power.
• 16 ft/min lifting speed provides efficient overhead lifting and controlled load positioning.
• Single-fall load chain configuration delivers dependable lifting performance.
• 14 ft lift accommodates elevated workstations and overhead material handling requirements.
• 12 ft pendent drop provides comfortable floor-level operation.
• Plain trolley allows smooth manual travel along compatible beam systems.
• Pendent control enables accurate raising and lowering of suspended loads.
• H4 (2m) duty classification supports frequent industrial lifting service.
• Compact ELK Series construction is suitable for manufacturing, warehouse, maintenance, and assembly environments.

Made in USA:

Applications:

• Manufacturing facilities.
• Assembly operations.
• Warehouse material handling.
• Maintenance and repair departments.
• Machine installation and servicing.
• General industrial overhead lifting requiring manual trolley travel.

FAQs:

• Q: What is the rated lifting capacity of this hoist?
  A: This model is rated for 1/2 ton (1,100 lbs).
• Q: What lifting speed does this hoist provide?
  A: The hoist lifts at 16 ft/min (5 m/min).
• Q: How many chain falls does this hoist use?
  A: This model uses a single-fall load chain configuration.
• Q: What is the headroom of this hoist?
  A: The headroom is 19.2 inches (488 mm).
• Q: What type of trolley is included?
  A: This model is equipped with a manually operated plain trolley for horizontal travel along compatible beam systems.
• Q: What duty classification does this hoist have?
  A: It carries an H4 (2m) duty rating for frequent industrial lifting operations.

Looking for more information about Ingersoll Rand Electric Hoist? Click here to view the Catalog

Need more feet of chain or a longer pendant hose? How about a motorized trolley? Give us a call at 1-800-608-5210 or email info@intlairtool.com. We can help!
