Ingersoll Rand ELK50-1ND50H-15-11-3CF15 ELK Series Electric Chain Hoist | 1/2 Ton Capacity | 15 ft Lift | 11 ft Drop | Hook Suspension | Pendent Control

Ingersoll Rand ELK50-1ND50H-15-11-3CF15 ELK Series Electric Chain Hoist delivers dependable electric lifting performance for production, maintenance, and material handling applications requiring a 1/2 Ton (1,100 lbs) lifting capacity. Equipped with a 15 ft lift, 11 ft pendent drop, hook suspension, and pendent control, this hoist is designed for smooth, accurate load positioning in manufacturing facilities, warehouses, maintenance shops, and other industrial environments. Built on the ELK50 platform, it offers dependable lifting performance with dual lifting speeds for improved productivity and precise load handling.

Designed for demanding industrial service, this ELK Series electric chain hoist features a compact construction, H4 duty classification, and hook suspension for quick installation on compatible overhead support structures. The ergonomic pendent control allows operators to safely raise and lower loads while maintaining precise control throughout the lifting cycle.

Type: Electric Chain Hoist | Series: ELK Series | Model: ELK50-1ND50H-15-11-3CF15 | SKU: ELK50-1ND50H-15-11-3CF15 | Capacity: 1/2 Ton (1,100 lbs) | Lift: 15 ft | Pendent Drop: 11 ft | Suspension: Hook | Control Type: Pendent Control | Lifting Speed: 32/8 ft/min | Duty Rating: H4 (2m) | Headroom: 19.2 in. | Approx. Weight (10 ft Lift): 57.3 lbs

Features:

• Rated lifting capacity of 1/2 ton (1,100 lbs) for industrial material handling applications.
• Dual lifting speeds of 32/8 ft/min provide efficient lifting with precise load positioning.
• 15 ft lift height accommodates a wide range of production and maintenance operations.
• 11 ft pendent drop offers comfortable operator access from floor level.
• Hook suspension enables fast installation on compatible overhead support structures.
• Pendent control delivers smooth and accurate raising and lowering of suspended loads.
• Compact ELK Series construction maximizes available workspace while simplifying installation.
• H4 (2m) duty classification supports frequent industrial lifting operations.
• Designed for dependable performance in manufacturing, maintenance, assembly, and warehouse environments.

Made in USA:

Applications:

• Manufacturing facilities.
• Assembly workstations.
• Maintenance and repair departments.
• Warehouse material handling.
• Machine installation and servicing.
• General industrial overhead lifting.

FAQs:

• Q: What is the lifting capacity of this hoist?
  A: This model has a rated lifting capacity of 1/2 ton (1,100 lbs).
• Q: What lifting speeds does this hoist provide?
  A: The ELK50-1ND50H-15-11-3CF15 offers dual lifting speeds of 32/8 ft/min for efficient lifting and precise load positioning.
• Q: What does the 15 ft lift specification indicate?
  A: It represents the maximum vertical travel of the load hook.
• Q: What is the purpose of the 11 ft pendent drop?
  A: The 11 ft pendent drop positions the control station at a comfortable operating height below the hoist.
• Q: How is this hoist mounted?
  A: This model features a hook suspension for attachment to a compatible overhead support structure.
• Q: What duty classification does this hoist have?
  A: This model is rated for H4 (2m) duty, making it suitable for frequent industrial lifting applications.

Looking for more information about Ingersoll Rand Electric Hoist? Click here to view the Catalog

Need more feet of chain or a longer pendant hose? How about a motorized trolley? Give us a call at 1-800-608-5210 or email info@intlairtool.com. We can help!
