Ingersoll Rand 9RSQ83 Pneumatic Angle Nutrunner | 1/2" Drive Size | 300 RPM | 82.0 (in-lbs) Torque

Ingersoll Rand 9RSQ83 Pneumatic Angle Nutrunner delivers a 300 RPM free speed and up to 82 ft-lbs maximum torque. Part of the 9 Series, this reversible air-powered nutrunner uses a stall mechanism, which allows the motor to slow and stop as fastening resistance increases. Its 1/2-inch square drive accommodates compatible fastening sockets, while the right-angle head provides access to bolts and nuts positioned near equipment frames, structural components, and assembly fixtures. The tool is recommended for soft pull applications, where fastening resistance builds gradually and critical torque accuracy is not required.

The 9RSQ83 incorporates lever-start actuation and convenient push-button reversing for fastener installation and removal. Its 1-inch side-to-center distance and 1.8-inch angle head height provide important clearance measurements when working around adjacent components. Measuring 17.9 inches in overall length and weighing 7.6 lbs, the nutrunner provides the size and leverage needed for higher-torque pneumatic fastening. Torque output can be influenced through air pressure regulation or operator control, making consistent air supply conditions important during use. The tool requires a 1/2-inch NPT air inlet, a 1/2-inch minimum air hose, and 65 CFM air consumption for its specified operating requirements.

Type: Pneumatic Angle Nutrunner | Model: 9RSQ83 | Series: 9 Series | Clutch Type: Stall | Maximum Torque: 82 ft-lbs | Free Speed: 300 RPM | Drive Size: 1/2 in. | Drive Type: Square Drive | Actuation: Lever Start | Reverse Control: Push-Button Reverse | Tool Weight: 7.6 lbs | Overall Length: 17.9 in. | Side-to-Center Distance: 1.0 in. | Angle Head Height: 1.8 in. | Air Consumption: 65 CFM | Air Inlet: 1/2 in. NPT | Minimum Hose Size: 1/2 in. | Sound Level: 82 dBA

Features: Stall-type operation permits torque control through air pressure regulation or operator control. 1/2-inch square drive accommodates compatible fastening sockets for nut and bolt installation. Lever-start actuation allows operators to control tool engagement during assembly operations. Convenient push-button reverse simplifies direction changes during fastener removal, adjustment, and reinstallation. Right-angle head configuration allows socket access to fastening locations where straight tools cannot be conveniently positioned. 300 RPM free speed provides controlled fastener rundown for assembly applications requiring higher torque at lower rotational speed.

Made in USA:

Applications:

• Heavy machinery assembly: Installing threaded fasteners on suitable equipment frames, housings, and mechanical components.
• Industrial manufacturing: Performing repetitive fastening operations where higher torque and angled access are required.
• Equipment fabrication: Tightening nuts and bolts on compatible fabricated assemblies and mounting structures.
• Production equipment assembly: Fastening components around fixtures, brackets, and confined mechanical interfaces.
• Industrial maintenance and rework: Removing and reinstalling threaded fasteners during equipment servicing and assembly adjustments.

FAQs:

• Q: What is the maximum torque of the Ingersoll Rand 9RSQ83?
  A: The 9RSQ83 provides up to 82 ft-lbs of torque with a free speed of 300 RPM. The manufacturer identifies this model as a 9 Series stall-type angle nutrunner.
• Q: Does the 9RSQ83 automatically shut off at a preset torque?
  A: No. This model uses a stall mechanism rather than a calibrated automatic shut-off clutch. Torque is influenced by operating air pressure and load resistance, so it is recommended for soft pull applications that do not require critical torque control.
• Q: What socket drive does the 9RSQ83 use?
  A: It features a 1/2-inch square drive for compatible fastening sockets. The socket and fastening arrangement must be suitable for the required torque and workpiece.
• Q: Can the Ingersoll Rand 9RSQ83 remove threaded fasteners?
  A: Yes. Its push-button reverse function allows the operator to change rotation direction for loosening, removing, or repositioning fasteners during assembly and maintenance work.
• Q: What compressed-air supply is required for the 9RSQ83?
  A: The manufacturer specifies 65 CFM air consumption, a 1/2-inch NPT air inlet, and a 1/2-inch minimum air hose. An appropriately sized air supply is important because operating pressure affects stall torque performance.
