Ingersoll Rand 17RA008 Spur Gear Reversible Multi-Vane Air Motor | 2.3 HP | 760 RPM | 35 (ft-lbs) Starting Torque | 54.5 (ft-lbs) Stall Torque

Ingersoll Rand 17RA008 Spur Gear Reversible Multi-Vane Air Motor is designed to provide dependable pneumatic rotary power for industrial applications requiring reversible operation, controlled speed, and increased torque output. This air motor delivers 2.3 HP with a free speed of 760 RPM. Its spur-gear and multi-vane configuration provides a pneumatic drive solution for compatible OEM machinery, production equipment, and rotary applications that require bidirectional operation.

The 17RA008 provides 35 ft-lbs starting torque, offering a reference for the torque available to initiate rotation from rest, and 54.5 ft-lbs stall torque, representing the maximum torque produced when the output shaft is prevented from rotating. The reversible design allows operation in both rotational directions, while the 760 RPM speed provides a balance between rotary speed and torque capability for compatible equipment.

Type: Spur Gear Multi-Vane Air Motor | Model: 17RA008 | Rotation: Reversible | Power: 2.3 HP | Free Speed: 760 RPM | Starting Torque: 35 ft-lbs | Stall Torque: 54.5 ft-lbs

Features:

• Spur gear and multi-vane configuration provides pneumatic rotary power for compatible industrial equipment.
• Reversible operation allows clockwise and counterclockwise rotation for applications requiring directional flexibility.
• 2.3 HP output provides substantial pneumatic power for compatible machinery and drive systems.
• 760 RPM free speed supports controlled rotary operation with increased torque capability.
• 35 ft-lbs starting torque provides a manufacturer-published reference for startup torque capability.
• 54.5 ft-lbs stall torque provides a manufacturer-published reference for maximum torque output under stalled conditions.
• The 17RA008 configuration provides a pneumatic alternative for equipment designed around compatible rotary motor specifications.
• Reversible operation allows the motor to be integrated into equipment requiring changes in rotational direction.

Made in USA:

Applications:

• OEM machinery requiring reversible pneumatic rotary power.
• Industrial production and processing equipment.
• Rotary drive systems requiring bidirectional operation.
• Material handling and compatible automated equipment.
• Replacement installations where the motor's power, speed, torque, and rotation characteristics match the existing equipment requirements.

FAQs:

• Q: Is the Ingersoll Rand 17RA008 reversible?
  A: Yes. The 17RA008 is specified as a reversible air motor and is designed for operation in both rotational directions.
• Q: What does spur gear mean on this air motor?
  A: Spur gear refers to the gear configuration incorporated into the motor. The 17RA008 combines this configuration with a multi-vane pneumatic motor.
• Q: What is the rated free speed of the 17RA008?
  A: The specified free speed is 760 RPM.
• Q: What is the starting torque of the 17RA008?
  A: The specified starting torque is 35 ft-lbs, providing a reference for the motor's torque capability when initiating rotation.
• Q: What is the stall torque of the 17RA008?
  A: The specified stall torque is 54.5 ft-lbs, representing the published torque output when the motor is stalled.
• Q: What should be checked before installation?
  A: Verify the required horsepower, operating speed, rotation direction, torque requirements, shaft and mounting configuration, and other equipment interface specifications before installation.
