Dotco 12L1380-36RT Right Angle Router | 12 Series | Gearless Drive | 0.3 HP | 30,000 RPM | Rear Exhaust

When clean edge finishing and controlled routing are required in confined work areas, the Dotco 12L1380-36RT right angle router delivers the speed needed for precision trimming without sacrificing maneuverability. Equipped with a 0.3 HP pneumatic motor and a 30,000 RPM free speed, this compact router is well suited for trimming composites, plastics, fiberglass, laminates, and other non-ferrous materials. Its gearless drive (a direct-drive design that transfers motor power straight to the spindle without reduction gears) provides responsive cutting performance while minimizing mechanical complexity.

The rear exhaust configuration directs spent air away from the work surface and operator, helping maintain better visibility during precision routing and finishing operations. Combined with a 1/4" shank capacity, lightweight construction, and right-angle head, the 12L1380-36RT offers excellent accessibility for production environments where accuracy and consistent handling are essential.

Type: Right Angle Router | Series: 12 Series | Drive: Gearless | Power: 0.3 HP (0.22 kW) | Free Speed: 30,000 RPM | Exhaust: Rear | Shank Capacity: 1/4" | Weight: 1.5 lb (0.68 kg) | Overall Length: 7.4" (188 mm) | Air Inlet: 1/4"

Features:

• Gearless direct-drive design provides high-speed routing performance with fewer drivetrain components.
• 30,000 RPM free speed supports fast trimming and smooth edge finishing.
• Right angle head improves access around fixtures, corners, and confined workspaces.
• Rear exhaust directs spent air away from the operator and finished work surface.
• 0.3 HP pneumatic motor delivers dependable power for precision routing applications.
• Accepts industry-standard 1/4-inch shank router bits.
• Compact, lightweight construction helps reduce fatigue during repetitive routing tasks.

Note: Router Template Guide is not included; it is sold separately.

Made in USA:

Applications:

• Composite fabrication for trimming carbon fiber and fiberglass components.
• Aerospace manufacturing where accurate edge finishing and confined-space access are required.
• Plastic and laminate fabrication for routing, profiling, and finishing operations.
• Industrial production environments performing repetitive template-guided routing.
• General fabrication shops requiring a compact pneumatic router for non-ferrous materials.

FAQs:

• Q: What is the benefit of the rear exhaust configuration?
  A: Rear exhaust directs discharged air away from the workpiece and operator, helping keep chips and debris from being blown across the cutting area while improving operator comfort.
• Q: What type of router bits can this tool use?
  A: The 12L1380-36RT accepts router bits with a 1/4-inch shank. Always use accessories rated for at least the tool's 30,000 RPM operating speed.
• Q: What does a gearless drive provide?
  A: A gearless drive transfers motor power directly to the spindle, providing responsive high-speed operation with fewer moving drivetrain components than geared designs.
• Q: Which materials is this router intended to machine?
  A: It is commonly used for trimming and routing composites, fiberglass, plastics, laminates, and other non-ferrous materials using the appropriate cutting accessories.
