Coxreels 1125PCL-8408M-A Air Motor Rewind Cord Reel | 1125PC Series | 125' (8/4) Capacity | 40 Amps | 600 Volts | Less Cord

Built for managing long runs of high-capacity power cable in shops, plants, and mobile service equipment, the Coxreels 1125PCL-8408M-A is an air motor rewind cord reel from the 1125PC Series. This model stores up to 125 ft of 8/4 SEOOW cord with a .78 in. cord O.D., giving installers a compact reel platform for larger 4-conductor power cord where loose cable on the floor can create clutter, trip hazards, and handling delays. The 40 amp, 600 volt, 4-pole slip ring configuration supports multi-conductor power transfer through the rotating drum, while the air motor rewind lets the reel retrieve cable without manual cranking when compressed air is available.

The 1125PCL-8408M-A uses Coxreels all-welded steel 'A' frame, drum-located slip ring assembly, and permanently lubricated self-aligning pillow block bearings to support smooth reel rotation and routine service access. The 'less cord' configuration is useful for buyers who need to install their own approved cord type, length, insulation rating, or site-specific wiring arrangement.

Type: Air Motor Rewind Cord Reel | Series: 1125PC Series | Model: 1125PCL-8408M-A | Configuration: Less Cord | Rewind Type: Air Motor | Cord Capacity: 125 ft of 8/4 SEOOW Cord | Cord O.D.: .78 in. | Cord Grip Range: .75-.85 in. | Voltage Rating: 600 V | Slip Ring Amps: 40 Amps | Slip Ring Poles: 4 | Approx. Weight: 43 lbs | Motor Option: A - Air, 4 Vane Aluminum Body Air Motor

Features:

• Air motor rewind helps retrieve long cable runs without manual cranking, useful for service vehicles, maintenance bays, and fixed work areas with compressed air available.
• Drum-located slip ring assembly includes an easy-access cover for routine maintenance without unnecessary reel disassembly.
• 4-pole, 40 amp slip ring configuration is rated at 600 volts for compatible multi-conductor power cord installations.
• All welded steel 'A' frame construction strengthens the reel structure and supports reliable mounting in shop, plant, and vehicle environments.
• Narrow-width frame helps fit the reel into restricted mounting spaces where a wider cord reel may interfere with nearby equipment.
• Permanently lubricated self-aligning pillow block bearings support smooth drum rotation during payout and rewind.
• 3/4" trade size single gang outlet box provides external access to lead connections.
• Adjustable tension brake helps prevent free-wheeling during operation, while the long-handled locking pin secures the reel during transport or storage.

Made in USA:

2 Year Warranty

Applications:

• Manufacturing plants and facilities managing long power cord runs for equipment, workstations, and maintenance areas.
• Service, mechanic, and utility vehicles where organized cord storage helps keep cable controlled during field work and transport.
• General industrial MRO areas that need a cord reel platform for larger 4-conductor power cable.
• Construction, mining, and railroad operations where power cord storage and retrieval must be planned around rugged work environments.
• Shop lighting and portable power-tool setups when the installed cord, electrical rating, and local code requirements match the application.

FAQs:

• Q: What does 'less cord' mean on this Coxreels model?
  A: It means the reel is supplied without cord installed. The buyer must provide compatible cord separately and ensure the cord gauge, insulation rating, length, service type, and installation method match the application.
• Q: What cord size does the 1125PCL-8408M-A store?
  A: This model is listed for 125 ft of 8/4 SEOOW cord with a .78 in. outside diameter. The cord grip range is .75-.85 in.
• Q: What does the 4-pole slip ring do?
  A: A slip ring transfers electrical power through the rotating drum while the cord is paid out or rewound. This model uses a 4-pole slip ring rated at 40 amps and 600 volts.
• Q: Does the amp rating change when more than three poles are energized?
  A: Coxreels notes that the reel should be de-rated by 20% if energizing more than 3 poles. Electrical service, cord rating, local code requirements, and the lowest-rated component in the system must all be considered before use.
• Q: Should the cord be fully unwound before energizing?
  A: Coxreels cautions that the cord should be completely unspooled from the reel when energized unless proper NEC ampacity derating factors are applied. Disconnect the power source while unspooling or spooling cord.
