Cleco PTW25IC Preset Mechanical Torque Wrench | Interchangeable Head | 3.6 - 18.4 (in-lbs) Torque Range

When small-to-medium fasteners need a fixed torque target across repeated assembly work, the Cleco PTW25IC Preset Mechanical Torque Wrench helps keep tightening consistent from operator to operator. Its 5 - 25 Nm torque range equals 44 - 221 in-lbs or 3.6 - 18.4 ft-lbs, making it suitable for controlled fastening on brackets, housings, panels, covers, and other components that require more torque than miniature inch-pound tools but less than larger maintenance wrenches. The interchangeable head interface allows compatible heads to be matched to the fastener location, giving assembly and inspection teams more access options without changing wrench bodies.

As a preset mechanical torque wrench, the PTW25IC is set for a specific torque value rather than adjusted freely during every job. That preset format is useful on production benches, tool cribs, and quality-controlled maintenance procedures where the goal is repeatability, not frequent adjustment. Its included 120XP ratcheting head uses a tight 3° swing arc, helping technicians work in confined areas where a wider ratchet movement would slow the job down.

Type: Preset Mechanical Torque Wrench | Model: PTW25IC | Torque Range: 5 - 25 Nm / 44 - 221 in-lbs / 3.6 - 18.4 ft-lbs | Head Type: Interchangeable | Interchange Size: 9 x 12 mm | Output Drive: 3/8" | Length Without Head: 231 mm / 9.1" | Weight Without Head: 0.47 kg / 1.04 lb

Features:

• Preset mechanical torque wrench format supports repeated fastening at a controlled target torque.
• Torque accuracy of +/-4% CW for precise control in safety- and quality-critical tightening applications.
• Designed and tested for 100K cycles before recertification, helping support planned calibration intervals.
• Industry-standard 9 x 12 mm interchange size works with compatible interchangeable heads.
• Supplied with a 120XP ball lock ratchet head for socket-driven fastening work.
• Minimal 3° ratchet swing arc improves access when there is limited room to move the handle.
• Compact 231 mm / 9.1" body length without head balances reach and control for bench and maintenance use.
• Conforms with ASME B107.300-2022 standards and specifications.

Made in USA:

Applications:

• Production assembly — applying the same preset torque to repeated fastening operations on brackets, covers, housings, and subassemblies.
• Quality control and torque auditing — checking fasteners during inspection, rework, and process verification where repeatable torque matters.
• Industrial maintenance & MRO — tightening machine guards, fixture hardware, panels, and service components to specified torque values.
• Automotive, fleet, and equipment service — supporting controlled torque on smaller 3/8" drive fasteners where the 3.6 - 18.4 ft-lbs range is appropriate.
• Tool crib standardization — assigning a preset wrench to a defined procedure to help reduce setting variation across users and shifts.

FAQs:

• Q: What torque range does the Cleco PTW25IC cover?
  A: The PTW25IC covers 5 - 25 Nm, which equals 44 - 221 in-lbs or 3.6 - 18.4 ft-lbs. This places it above very low inch-pound screw fastening tools and below larger ft-lb torque wrenches used for heavy maintenance bolts.
• Q: What does “preset mechanical torque wrench” mean?
  A: It means the wrench is set to a specified torque value for repeated use. This helps reduce operator adjustment and supports consistent fastening on production or quality-controlled maintenance tasks.
• Q: What does the interchangeable head feature allow?
  A: The 9 x 12 mm interchangeable interface lets the wrench accept compatible heads for different access needs. This is useful when a straight ratchet head, flex head, or other compatible head style is needed for a specific fastener location.
• Q: Is a ratcheting head included with this wrench?
  A: Yes. Cleco lists the preset mechanical torque wrench family as including a 120XP ratcheting head. The 120XP head has a 3° swing arc to help in tight spaces.
• Q: Is this model for lug nuts or high-torque bolts?
  A: No. The PTW25IC is a low-to-mid torque preset wrench. For wheel lug nuts, structural fasteners, or larger service bolts, choose a Cleco torque wrench with a higher ft-lb capacity.
