Cleco 135DPV-7B-43 Non-Reversible Variable Speed Pistol Drill | 135DPV Series | 600 RPM | 1/2" Chuck | Rear Exhaust

Built for controlled hole drilling in production, fabrication, and maintenance work, the Cleco 135DPV-7B-43 Non-Reversible Variable Speed Pistol Drill delivers 0.7 HP power with a 600 RPM free speed for larger holes, lower-speed drilling, and jobs where torque control matters more than high-speed cutting. The variable speed range allows the operator to slow the tool for starting holes and adjust drilling speed for different materials, while the pistol grip layout provides familiar hand positioning for bench work, fixture drilling, and general shop use.

The 135DPV Series uses calibrated governed speed control, meaning the tool can be set within a defined speed range to better match hole size, drill bit diameter, and workpiece material. Its rear exhaust directs spent air away from the work area, helping keep chips and debris from blowing across the drilling surface during repeated use.

Type: Non-Reversible Variable Speed Pistol Drill | Series: 135DPV Series | Model: 135DPV-7B-43 | Power: 0.7 HP / 0.52 kW | Free Speed: 600 RPM | Governed Speed Range: 150–550 RPM | Chuck Capacity: 3/8" Heavy Duty | Housing: Aluminum | Length: 9.6" / 244 mm | Weight: 3.6 lbs / 1.63 kg | Air Inlet: 1/4" NPT | Minimum Hose Size: 1/4" / 6 mm | Exhaust: Rear

Features:

• Variable speed operation helps one drill cover multiple hole sizes and drilling conditions.
• Calibrated governed speed control provides defined minimum and maximum speed settings for more repeatable drilling performance.
• 600 RPM free speed supports larger drill bits and controlled hole-making where slower cutting speed is preferred.
• 0.7 HP motor output gives the drill the power needed for production drilling, fixture work, and general fabrication tasks.
• Non-reversible configuration keeps the tool focused on forward drilling applications.
• Rear exhaust directs air away from the drilling point to help reduce chip disturbance around the work surface.
• Aluminum housing keeps tool weight to 3.6 lbs while supporting regular shop and assembly use.

Applications:

• Fabrication shops — drilling holes in brackets, panels, fixtures, and light structural components.
• Production assembly — repeated hole drilling where a governed-speed air drill helps standardize tool performance across workstations.
• Maintenance and MRO — repair drilling, rework, and replacement-part preparation in plant and equipment service areas.
• Fixture and jig work — controlled drilling in templates, drill guides, and bench-mounted assemblies.
• General shop use — pneumatic drilling tasks where a pistol grip air drill is preferred over an electric drill for continuous air-powered operation.

FAQs:

• Q: Is the Cleco 135DPV-7B-43 reversible?
  A: No. This model is listed as a non-reversible variable speed pistol drill, so it is intended for forward drilling applications rather than backing out fasteners or reversing drill bits.
• Q: What does governed speed control mean?
  A: Governed speed control limits and regulates the tool’s operating speed within a defined range. This helps the operator match drill speed to hole size, bit diameter, and material instead of relying only on trigger feel.
• Q: What chuck size does this SKU use?
  A: Manufacturer catalog data identifies 135DPV-7B-43 with a 3/8" heavy duty chuck. The supplied page title says 1/2" chuck, so this should be verified before publishing or ordering.
• Q: When would I choose a 600 RPM air drill?
  A: A 600 RPM drill is useful for slower, more controlled drilling, especially with larger bits or tougher materials where excessive speed can reduce bit life or make hole starting less stable.
• Q: What air line should be used with this drill?
  A: The general air connection data lists a 1/4" NPT air inlet and 1/4" minimum hose size. Use clean, regulated, lubricated air supply sized for the drill and the duty cycle of the application.
