When clearance is limited but the fastener still needs real impact power, the AIRCAT 1076-XL 3/8" NITROCAT Composite Compact Impact Wrench gives technicians a short, high-output tool for automotive, fleet, and shop service work. Its 550 ft-lbs maximum torque supports stubborn fastener removal in a compact package, while 750 ft-lbs of loosening torque helps break loose tight or corroded bolts before run-down. The 3/8" square drive fits common 3/8" impact sockets, and the 9,000 RPM free speed helps move quickly through repeated fastening jobs once the fastener is started.
At only 4.25" long and 2.5 lbs., the 1076-XL is sized for engine-bay work, suspension areas, body shop repairs, and compact equipment service where a full-size impact wrench can be difficult to position. The jumbo hammer mechanism (the internal impact system that delivers repeated striking force to the anvil) helps transfer power reliably, while the low weight composite housing keeps the tool manageable during repetitive use. AIRCAT's patented Silencing Technology reduces the noise level to 85 dBA, making this compact impact a practical choice for busy service environments.
Type: Composite Compact Impact Wrench | Model: 1076-XL | Drive Size: 3/8" Square Drive | Free Speed: 9,000 RPM | Bolt Capacity: 9/16" | Impacts Per Minute: 1,650 IPM | Max Torque: 550 ft-lbs | Loosening Torque: 750 ft-lbs | Weight: 2.5 lbs. | Length: 4.25" | Air Consumption: 8 CFM | Recommended Hose Size: 3/8" | Air Inlet: 1/4" NPT/BSP | Noise Level: 85 dBA | Vibration: 9.9 m/sec²
Features:
- Provides 550 ft-lbs of maximum torque and 750 ft-lbs of loosening torque for compact fastening and removal work.
- Low weight composite housing reduces tool weight to 2.5 lbs. for better handling during repeated service tasks.
- Reliable jumbo hammer mechanism delivers maximum power while increasing reliability.
- Patented Silencing Technology reduces the noise level to 85 dBA.
- Patented grip is shaped to fit the hand and support controlled operation during tight-access work.
- Patented trigger-mounted combined forward/reverse and power management switch provides control and one-hand operation.
- Compact 4.25" length helps the tool fit into restricted areas where longer impact wrenches are difficult to use.
Applications:
- Automotive repair: Removing and installing fasteners around engines, brackets, suspension components, brake work, and underbody areas where tool clearance is limited.
- Fleet maintenance: Servicing panels, guards, mounts, and compact chassis fasteners on trucks, vans, trailers, and shop equipment.
- Body shops and collision repair: Handling impact fastening on panels, brackets, bumper hardware, and compact repair areas where a shorter tool improves access.
- Industrial maintenance and MRO: Running down and removing bolts on machinery covers, fixtures, equipment frames, and repair benches.
- DIY garage and restoration work: Useful for experienced home mechanics working on automotive projects, rusted hardware, and tight-access repair jobs with a properly sized air supply.
FAQs:
- Q: What is the benefit of a compact impact wrench?
A: A compact impact wrench gives you impact power in areas where a full-size tool may not fit. The 1076-XL is 4.25" long, making it useful around engine compartments, suspension areas, machinery frames, and other tight service spaces. - Q: Can I use regular chrome sockets with the AIRCAT 1076-XL?
A: No. Use impact-rated 3/8" drive sockets only. Chrome hand sockets are not built for repeated impact loads and may crack or fail when used with an air impact wrench. - Q: What air hose size does this tool need?
A: AIRCAT lists a 3/8" recommended hose size for the 1076-XL. A properly sized hose helps maintain airflow so the tool can deliver its rated speed and torque. - Q: What does 750 ft-lbs loosening torque mean?
A: Loosening torque is the breakaway force available for removing tightened or stuck fasteners. The 550 ft-lbs maximum torque rating describes headline output, while the 750 ft-lbs loosening torque reflects the tool's removal capability. - Q: Is this a good tool for lug nuts?
A: The 1076-XL may remove some automotive lug nuts when fastener condition and torque requirements are within the tool's range. For frequent tire service, larger vehicles, or heavily corroded wheel hardware, a 1/2" drive impact wrench is usually the better primary choice. Final tightening should always be checked with a calibrated torque wrench.
| SKU | Free Speed (RPM) | Bolt Capacity (in.) | Square Drive (in.) | Impacts Per Minute | Max. Torque (ft-lb) @90 psi | Weight (lbs.) | Length (in) | Air Cons. (CFM) | Rec. Hose Size (in.) | Air Inlet NPT (in.) |
|---|---|---|---|---|---|---|---|---|---|---|
| 1076-XL | 9,000 | 9/16 | 3/8 | 1650 | 550 | 2.50 | 4.25 | 8 | 3/8 | 1/4 |
| 1059-VXL | 9,000 | 9/16 | 3/8 | 1700 | 550 | 2.80 | 4.40 | 8 | 3/8 | 1/4 |
| 1059-VXL-P | 9,000 | 9/16 | 3/8 | 1700 | 550 | 2.80 | 4.40 | 8 | 3/8 | 1/4 |
Looking for more information about the Aircat Pneumatic Impact Wrenches? For help choosing the correct Aircat Pneumatic Tools, please call (800) 608-5210 or email info@intlairtool.com
