When a compact impact wrench needs more control over vibration without giving up torque, the AIRCAT 1059-VXL 3/8" VIBROTHERM DRIVE Composite Compact Impact Wrench gives technicians a short-body pneumatic tool for tight automotive, fleet, and maintenance work. Its 550 ft-lbs maximum torque supports stubborn fastener removal in restricted spaces, while 750 ft-lbs of loosening torque helps break loose tight or corroded bolts before run-down. The 3/8" square drive fits common 3/8" impact sockets, and the 9,000 RPM free speed keeps repetitive fastening work moving efficiently.
At 4.40" long and 2.80 lbs., the 1059-VXL is sized for engine bays, suspension areas, underbody hardware, and compact equipment where larger impact wrenches are difficult to position. The VIBROTHERM DRIVE® mechanism (AIRCATs patented impact design built to reduce vibration while maintaining impact power) lowers vibration levels by 30%40% and increases mechanism life by 50%. AIRCAT's patented muffler system keeps noise low, while the composite housing and molded grip support better handling during repeated service work.
Type: VIBROTHERM DRIVE Composite Compact Impact Wrench | Model: 1059-VXL | Drive Size: 3/8" Square Drive | Free Speed: 9,000 RPM | Bolt Capacity: 9/16" | Impacts Per Minute: 1,700 IPM | Max Torque: 550 ft-lbs 90 PSI | Loosening Torque: 750 ft-lbs | Weight: 2.80 lbs. | Length: 4.40" | Air Consumption: 8 CFM | Recommended Hose Size: 3/8" | Air Inlet: 1/4" NPT
Features:
- Provides 550 ft-lbs of maximum torque and 750 ft-lbs of loosening torque for compact fastening and removal work.
- VIBROTHERM DRIVE impact wrench mechanism incorporates AIRCAT's patented impact design.
- Patented VIBROTHERM DRIVE hammer mechanism reduces vibration levels by 30% - 40% and increases the life of the tool by 50%.
- Patented AIRCAT muffler system helps provide low noise output during pneumatic impact operation.
- Composite housing keeps the tool weight to 2.80 lbs. for improved handling in repeated service tasks.
- Patented grip design supports controlled handling when working in compact or awkward tool positions.
- Triple injection molding process supports AIRCAT's distinctive composite body design.
Applications:
- Automotive repair: Removing and installing fasteners around engines, brackets, suspension components, brake hardware, and underbody areas where clearance is limited.
- Fleet maintenance: Servicing compact chassis fasteners, panels, guards, mounts, and smaller shop hardware on vans, trucks, trailers, and service equipment.
- Body shops and collision repair: Handling bumper brackets, panel hardware, support brackets, and tight-access fasteners where a shorter impact body improves control.
- Industrial maintenance and MRO: Running down and removing bolts on machinery covers, fixtures, equipment frames, access panels, and repair benches.
- DIY garage and restoration work: Useful for experienced home mechanics working on compact automotive projects, rusted hardware, and tight repair areas with a properly sized air supply.
FAQs:
- Q: What is VIBROTHERM DRIVE on the AIRCAT 1059-VXL?
A: VIBROTHERM DRIVE® is AIRCAT's patented impact mechanism design for this compact impact wrench. It is intended to reduce vibration levels by 30%-40% while increasing the life of the mechanism by 50%. - Q: How is the 1059-VXL different from a standard compact impact wrench?
A: The key difference is the VIBROTHERM DRIVE mechanism, which focuses on reducing vibration while maintaining compact impact power. This makes the 1059-VXL a strong choice when technicians want 3/8" drive access, 550 ft-lbs maximum torque, and lower vibration in the same tool category. - Q: What air hose size should I use with this impact wrench?
A: AIRCAT lists a 3/8" recommended hose size for the 1059-VXL. Using the recommended hose helps maintain air volume so the tool can deliver proper speed and torque under load. - Q: Can I use chrome hand sockets with this tool?
A: No. Use impact-rated 3/8" drive sockets only. Chrome hand sockets are not made for repeated impact loads and can crack or fail when used with pneumatic impact tools. - Q: Is this tool suitable for lug nuts?
A: The 1059-VXL may remove some passenger-vehicle lug nuts when the fastener condition and torque requirement are within the tool's capability. For frequent tire service, larger vehicles, or heavily corroded wheel hardware, a 1/2" drive impact wrench is usually the better primary tool. Final tightening should always be checked with a calibrated torque wrench.
| SKU | Free Speed (RPM) | Bolt Capacity (in.) | Square Drive (in.) | Impacts Per Minute | Max. Torque (ft-lb) @90 psi | Weight (lbs.) | Length (in) | Air Cons. (CFM) | Rec. Hose Size (in.) | Air Inlet NPT (in.) |
|---|---|---|---|---|---|---|---|---|---|---|
| 1076-XL | 9,000 | 9/16 | 3/8 | 1650 | 550 | 2.50 | 4.25 | 8 | 3/8 | 1/4 |
| 1059-VXL | 9,000 | 9/16 | 3/8 | 1700 | 550 | 2.80 | 4.40 | 8 | 3/8 | 1/4 |
| 1059-VXL-P | 9,000 | 9/16 | 3/8 | 1700 | 550 | 2.80 | 4.40 | 8 | 3/8 | 1/4 |
