Ingersoll Rand W7153 DXS Cordless Impact Wrench | 1/2" Square Drive | 1600 (ft-lbs) Breakaway Torque (Bare Tool Only, Battery Not Included)

Experience high-torque cordless performance with the Ingersoll Rand W7153 DXS Cordless Impact Wrench, designed for automotive, fleet, and industrial maintenance. Powered by the IQV20 20V battery platform, this brushless tool features a 1/2" square drive and the patented DXS Drive Xchange System for quickly swapping compatible anvils. Ingersoll Rand publishes up to 1,600 ft-lbs (2,170 Nm) of breakaway torque when used with specified 3/4" DXS drive accessories. The supplied manufacturer flyer rates the standard 1/2" configuration at 1,500 ft-lbs of breakaway torque. Its cordless design eliminates air hoses, making fastener removal more convenient in workshops and field-service locations.

The W7153 features four IQV Power Control modes, a variable-speed trigger with electronic brake, and a patented 360° Shadowless LED light ring for improved visibility. Its steel-reinforced frame, impact-resistant housing, and IPX6 water-resistance rating support demanding working conditions. Operating at up to 1,900 RPM with 2,450 impacts per minute, the wrench measures 8.3" long and weighs 6.1 lbs without a battery. This bare-tool configuration includes the standard 1/2" friction-ring DXS anvil (A41H); the battery and charger are not included.

Note: The above product image is for illustration purposes only. This product is a Bare Tool only and does not include any batteries and chargers. Please note this before ordering.

Type: Cordless High Torque Impact Wrench | Model: W7153 | Series: IQV20 DXS | Configuration: Bare Tool Only | Voltage: 20V | Motor: Brushless | Drive Size: 1/2" | Drive Type: Square, Friction Ring | Included Anvil: A41H, 1/2" Standard | Drive System: DXS Drive Xchange System | Breakaway Torque: 1,600 ft-lbs (2,170 Nm) | Free Speed: 1,900 RPM | Impacts Per Minute: 2,450 | Lighting: 360° LED Light Ring | Length: 8.3" (211 mm) | Bare Tool Weight: 6.1 lbs (2.76 kg) | Impacting Sound Level: 95 dB(A) | Battery Compatibility: Ingersoll Rand IQV20 | Battery and Charger: Not Included

Features:

• Patented DXS Drive Xchange System enables quick changes between compatible drive configurations without replacing the entire wrench.
• Tight-fitting DXS sockets and anvils transfer up to 15% more motor torque to fasteners compared with traditional square-drive sockets under the manufacturer's stated conditions.
• High breakaway torque supports removal of stubborn threaded fasteners during automotive and heavy equipment service.
• Four IQV Power Control modes—Full Power, Half Power, Wrench Tight, and Hand Tight—provide options for different fastening requirements.
• Variable-speed trigger and electronic brake provide responsive control and stop drive rotation when the trigger is released.
• Patented 360° Shadowless LED light ring illuminates the fastening area to improve visibility around recessed or obstructed components.
• Steel-reinforced frame and chemical- and impact-resistant housing provide protection against demanding workshop conditions.
• IPX6 water-resistance rating provides protection against powerful water jets under specified test conditions; the wrench is not intended for immersion.
• Compact body and premium overmolded grip support maneuverability and handling during repeated service operations.
• Compatible with Ingersoll Rand IQV20 batteries, allowing integration into an existing cordless tool collection.

Applications:

• Automotive tire and wheel service – Removing stubborn wheel fasteners using compatible impact-rated sockets.
• Fleet and commercial vehicle maintenance – Servicing chassis bolts, cradle bolts, and suitable mechanical fasteners.
• Industrial maintenance and MRO – Loosening threaded connections on machinery, equipment frames, and mechanical assemblies.
• Heavy equipment repair – Performing high-torque fastener removal where cordless mobility improves access and positioning.
• Mobile and field service – Working at maintenance locations where compressed-air hoses are unavailable or inconvenient.

FAQs:

• Q: Does the Ingersoll Rand W7153 deliver 1,600 ft-lbs of breakaway torque?
  A: Ingersoll Rand's current product page publishes a maximum breakaway rating of 1,600 ft-lbs. Additional manufacturer documentation specifies that this rating is achieved with 3/4" DXS drive accessories. The supplied 2024 flyer lists 1,500 ft-lbs for the standard 1/2" anvil configuration. Buyers should match the torque specification to the intended drive arrangement.
• Q: Does SKU W7153 include a battery and charger?
  A: No. W7153 is the bare-tool configuration. It includes the standard 1/2" DXS friction-ring anvil (A41H), but a compatible IQV20 battery and charger are required separately. Ingersoll Rand offers battery-and-charger packages under distinct kit numbers.
• Q: What is the DXS Drive Xchange System?
  A: DXS® uses a proprietary interchangeable drive connection that allows technicians to change compatible anvils. The manufacturer offers 3/8", 1/2", and 3/4" drive options, including extended versions, as separate accessories. This can reduce reliance on conventional drive adapters.
• Q: What are the four IQV Power Control modes?
  A: Full Power, Half Power, Wrench Tight, and Hand Tight provide different fastening-output options. They help operators select a mode suited to the job, but they do not provide calibrated final tightening torque.
• Q: Can the W7153 be used with existing IQV20 batteries?
  A: Yes. Ingersoll Rand identifies compatibility with its IQV20 battery platform. Manufacturer documentation specifies a 5.0Ah battery for maximum performance. Confirm battery condition and suitability before demanding fastening operations.
• Q: Is the W7153 suitable for outdoor maintenance?
  A: Its cordless design makes it useful for mobile service, and its IPX6 rating provides water-jet resistance under specified conditions. IPX6 does not mean the tool is waterproof or suitable for immersion. Follow the manufacturer's environmental and battery safety instructions.
