Ingersoll Rand SLB600-10 Silver Series Lever Chain Hoist | 10' Standard Lift | 3 (metric tons) Capacity | 1 Chain Falls

Built for controlled manual lifting, pulling, positioning, and rigging, the Ingersoll Rand SLB600-10 Silver Series Lever Chain Hoist provides a 3 metric ton (6,600 lb) rated capacity with a 10 ft standard lift and 1 chain fall. Its high-strength, all-stamped steel construction is designed to provide decreased weight and better impact resistance, while the Silver Series design combines compact manual operation with features intended to support efficient lifting, inspection, and maintenance.

The SLB600 requires 53 lb of pull to lift the rated load and uses a 10 x 30 mm load chain weighing 1.5 lb per foot. Encased and retained roller bearings support increased efficiency and ease of maintenance, while double-reduction gearing provides superior spotting characteristics and low handle effort. The short handle and stroke allow 360° operation for rigging in tight spaces. The manufacturer also specifies an automatic inertia brake that engages when a load is applied in free-chain mode, helping minimize operator setup error.

Type: Lever Chain Hoist | Series: Silver Series | Model: SLB600-10 | Capacity: 3 Metric Tons (6,600 lb) | Standard Lift: 10 ft | Chain Falls: 1 | Pull to Lift Rated Load: 53 lb | Load Chain Size: 10 x 30 mm | Chain Weight: 1.5 lb/ft | Minimum Headroom: 20.5 in | Shipping Weight with 10 ft Lift: 46 lb

Features:

• High-strength, all-stamped steel construction provides decreased weight and better impact resistance.
• Open-frame design facilitates cleaning and inspection.
• Encased and retained roller bearings support increased efficiency and ease of maintenance.
• Premium-grade alloy load chain provides the specified load-chain construction.
• Hardened swivel-latch hooks provide the specified hook configuration.
• Nickel- and chrome-plated exterior and zinc-plated frame components provide increased corrosion resistance.
• Double-reduction gearing provides superior spotting characteristics and low handle effort.
• Deep lug knobs facilitate one-handed operation with or without gloves.
• Short handle and stroke allow 360° operation for rigging in tight spaces.
• Automatic inertia brake engages when a load is applied in free-chain mode, helping minimize operator setup error.
• Single chain fall provides the specified lifting configuration for the 3 metric ton SLB600.
• Silver Series lever chain hoists meet or exceed ANSI B30.21 standards according to the manufacturer catalog.

Applications:

• Manual load positioning — provides controlled lifting and positioning of loads within the 6,600 lb rated capacity.
• Maintenance and repair — suitable for positioning equipment, components, and machinery where a manual lever hoist is appropriate.
• Rigging operations — the single-chain-fall configuration provides manual lifting and positioning capability for compatible loads.
• Confined-space rigging — the short handle and stroke allow 360° operation where operating space is limited.
• Material handling — the 10 ft standard lift provides vertical travel for applications requiring a 3 metric ton manual lever hoist.

FAQs:

• Q: What is the capacity of the SLB600-10?
  A: The SLB600-10 is rated for 3 metric tons, equivalent to 6,600 lb.
• Q: What does the 10 ft standard lift mean?
  A: It identifies this SKU as the SLB600 configuration supplied with a 10 ft lift.
• Q: How many chain falls does the SLB600-10 have?
  A: The SLB600 uses 1 chain fall.
• Q: How much pull is required to lift the rated load?
  A: The manufacturer specifies 53 lb of pull to lift the rated load.
• Q: What size load chain does the SLB600 use?
  A: The SLB600 uses a 10 x 30 mm load chain with a listed weight of 1.5 lb per foot.
• Q: What is the minimum headroom?
  A: The manufacturer specifies 20.5 in minimum headroom for the SLB600.
• Q: What is the shipping weight for the 10 ft SLB600?
  A: The manufacturer catalog lists 46 lb shipping weight with 10 ft of lift.
• Q: Can the SLB600-10 be operated in tight spaces?
  A: Yes. The short handle and stroke allow 360° operation for rigging in tight spaces.
• Q: Does the SLB600-10 include an overload clutch?
  A: The supplied Silver Series lever-hoist specifications do not identify an overload clutch as a separate feature for the SLB600. The catalog specifies an automatic inertia brake for free-chain operation.

Looking for more information about the Ingersoll Rand Hoist? Click here to view the Catalog

For help choosing the proper Ingersoll Rand Hoists for your assembly application, please email info@intlairtool.com or call (800) 608-5210
