Built for controlled manual lifting, pulling, positioning, and rigging, the Ingersoll Rand SLB200-5 Silver Series Lever Chain Hoist provides a 1 metric ton (2,200 lb) rated capacity with a 5 ft standard lift and 1 chain fall. Its high-strength, all-stamped steel construction is designed to reduce weight while improving impact resistance, making it suitable for demanding manual lifting applications where compact operation and controlled load positioning are required.
The SLB200 requires 60 lb of pull to lift the rated load and uses a 6 x 18 mm premium-grade alloy load chain. Encased and retained roller bearings support efficient operation and easier maintenance, while double-reduction gearing provides controlled spotting and low handle effort. An automatic inertia brake engages if a load is applied while the hoist is in free-chain mode, helping minimize operator setup error. The short handle and stroke allow 360° operation for rigging in tight spaces.
Type: Lever Chain Hoist | Series: Silver Series | Model: SLB200-5 | Capacity: 1 Metric Ton (2,200 lb) | Standard Lift: 5 ft | Chain Falls: 1 | Pull to Lift Rated Load: 60 lb | Load Chain Size: 6 x 18 mm | Chain Weight: 0.5 lb/ft | Minimum Headroom: 14.4 in
Features:
- High-strength, all-stamped steel construction provides decreased weight and better impact resistance.
- Open-frame design makes cleaning and inspection easier.
- Encased and retained roller bearings support increased efficiency and ease of maintenance.
- Premium-grade alloy load chain provides the specified load-chain construction.
- Hardened swivel-latch hooks provide the specified hook configuration.
- Nickel- and chrome-plated exterior and zinc-plated frame components provide increased corrosion resistance.
- Double-reduction gearing provides superior spotting characteristics and low handle effort.
- Double hand-chain guides provide smooth operation when pulling excess hand chain.
- Deep lug knobs facilitate one-handed operation with or without gloves.
- Short handle and stroke allow 360° operation for rigging in tight spaces.
- Automatic inertia brake engages if a load is applied while the hoist is in free-chain mode, helping minimize operator setup error.
- Silver Series lever chain hoists meet or exceed ANSI B30.21 standards according to the manufacturer catalog.
Applications:
- Manual load positioning — provides controlled lifting and positioning of loads within the 2,200 lb rated capacity.
- Maintenance and repair — useful for positioning equipment, components, and machinery where a manual lever hoist is appropriate.
- Confined-space rigging — the short handle and stroke support 360° operation where operating space around the hoist is limited.
- Material handling — the 5 ft lift configuration provides a short vertical lifting distance for applications where extended lift is not required.
FAQs:
- Q: What is the capacity of the SLB200-5?
A: The SLB200-5 is rated for 1 metric ton, equivalent to 2,200 lb. - Q: What does the 5 ft standard lift mean?
A: It identifies this SKU as the SLB200 configuration supplied with a 5 ft lifting distance. - Q: How many chain falls does the SLB200-5 have?
A: The SLB200 uses 1 chain fall. - Q: How much pull is required to lift the rated load?
A: The manufacturer specifies 60 lb of pull to lift the rated load. - Q: What size load chain does the SLB200 use?
A: The SLB200 uses a 6 x 18 mm load chain with a listed weight of 0.5 lb per foot. - Q: What is the minimum headroom?
A: The manufacturer specifies 14.4 in minimum headroom for the SLB200. - Q: Can the SLB200-5 be operated in tight spaces?
A: Yes. The short handle and stroke allow 360° operation for rigging in tight spaces. - Q: Does the SLB200-5 have an overload clutch?
A: The supplied Silver Series catalog does not identify an overload clutch as a standard feature for the SLB200. It does specify an automatic inertia brake that engages when a load is applied in free-chain mode.
| SKU | CAPACITY | # FALLS | PULL TO LIFT RATED LOAD |
CHAIN SIZE MM |
CHAIN WEIGHT PER FOOT |
SHIPPING WEIGHT WITH 10' OF LIFT |
||||
|---|---|---|---|---|---|---|---|---|---|---|
| LB | METRIC TONS | LB | KG | LB | KG | LB | KG | |||
| SLB150 | 1,650 | 0.75 | 1 | 41 | 18.6 | 6 x 18 | 0.5 | 0.2 | 16 | 7.3 |
| SLB200 | 2,200 | 1 | 1 | 60 | 27.3 | 6 x 18 | 0.5 | 0.2 | 16 | 7.3 |
| SLB300 | 3,300 | 1.50 | 1 | 53 | 24.1 | 7.1 x 21.2 | 0.7 | 0.3 | 26 | 11.8 |
| SLB600 | 6,600 | 3 | 1 | 53 | 24.1 | 10 x 30 | 1.5 | 0.7 | 46 | 20.9 |
| SLB1200 | 13,200 | 6 | 2 | 57 | 25.9 | 10 x 30 | 2.9 | 1.3 | 69 | 31.4 |
Looking for more information about the Ingersoll Rand Hoist? Click here to view the Catalog
For help choosing the proper Ingersoll Rand Hoists for your assembly application, please email info@intlairtool.com or call (800) 608-5210
