Designed for controlled manual lifting, pulling, positioning, and rigging, the Ingersoll Rand SLB1200-5 Silver Series Lever Chain Hoist provides a 6 metric ton (13,200 lb) rated capacity with a 5 ft standard lift and 2 chain falls. High-strength, all-stamped steel construction helps reduce weight while providing better impact resistance, while the Silver Series design combines a compact lever-hoist format with features intended for efficient operation, inspection, and maintenance.
The SLB1200 requires 57 lb of pull to lift the rated load and uses a 10 x 30 mm premium-grade alloy load chain weighing 2.9 lb per foot. Encased and retained roller bearings support increased efficiency and ease of maintenance, while double-reduction gearing provides superior spotting characteristics and low handle effort. An automatic inertia brake engages if a load is applied in free-chain mode, helping minimize operator setup error. The short handle and stroke allow 360° operation for rigging in tight spaces.
Type: Lever Chain Hoist | Series: Silver Series | Model: SLB1200-5 | Capacity: 6 Metric Tons (13,200 lb) | Standard Lift: 5 ft | Chain Falls: 2 | Pull to Lift Rated Load: 57 lb | Load Chain Size: 10 x 30 mm | Chain Weight: 2.9 lb/ft | Minimum Headroom: 25.2 in
Features:
- High-strength, all-stamped steel construction provides decreased weight and better impact resistance.
- Open-frame design facilitates cleaning and inspection.
- Encased and retained roller bearings support increased efficiency and ease of maintenance.
- Premium-grade alloy load chain provides the specified load-chain construction.
- Hardened swivel-latch hooks provide the specified hook configuration.
- Nickel- and chrome-plated exterior and zinc-plated frame components provide increased corrosion resistance.
- Double-reduction gearing provides superior spotting characteristics and low handle effort.
- Deep lug knobs facilitate one-handed operation with or without gloves.
- Short handle and stroke allow 360° operation for rigging in tight spaces.
- Automatic inertia brake engages if a load is applied in free-chain mode, helping minimize operator setup error.
- Overload protection is provided by a clutch that slips in the lifting direction only.
- Two chain falls provide the specified lifting configuration for the 6 metric ton SLB1200.
- CE-certified design meets or exceeds regional requirements including ASME B30.21 and HST-3M, according to the manufacturer catalog.
Applications:
- Heavy manual load positioning — provides controlled lifting and positioning of loads within the 13,200 lb rated capacity.
- Maintenance and repair — suitable for positioning heavy equipment, components, and machinery where a manual lever hoist is appropriate.
- Rigging operations — the two-chain-fall configuration supports the specified 6 metric ton lifting capacity.
- Industrial material handling — the 5 ft standard lift provides short vertical travel for heavy lifting and positioning tasks.
- Confined-space rigging — the short handle and stroke allow 360° operation where operating space is limited.
FAQs:
- Q: What is the capacity of the SLB1200-5?
A: The SLB1200-5 is rated for 6 metric tons, equivalent to 13,200 lb. - Q: What does the 5 ft standard lift mean?
A: It identifies this SKU as the SLB1200 configuration supplied with 5 ft of lifting travel. - Q: How many chain falls does the SLB1200-5 have?
A: The SLB1200 uses 2 chain falls. - Q: How much pull is required to lift the rated load?
A: The manufacturer specifies 57 lb of pull to lift the rated load. - Q: What size load chain does the SLB1200 use?
A: The SLB1200 uses a 10 x 30 mm load chain with a listed weight of 2.9 lb per foot. - Q: What is the minimum headroom?
A: The manufacturer specifies 25.2 in minimum headroom for the SLB1200. - Q: What is the shipping weight of the SLB1200-5?
A: The manufacturer catalog lists 69 lb shipping weight with 10 ft of lift. It does not provide a separate shipping-weight figure for the 5 ft configuration. - Q: Can the SLB1200-5 be operated in tight spaces?
A: Yes. The short handle and stroke allow 360° operation for rigging in tight spaces. - Q: Does the SLB1200-5 have overload protection?
A: Yes. The manufacturer specifies an overload clutch as standard equipment on Silver Series lever chain hoists. The clutch slips in the lifting direction only.
| SKU | CAPACITY | # FALLS | PULL TO LIFT RATED LOAD |
CHAIN SIZE MM |
CHAIN WEIGHT PER FOOT |
SHIPPING WEIGHT WITH 10' OF LIFT |
||||
|---|---|---|---|---|---|---|---|---|---|---|
| LB | METRIC TONS | LB | KG | LB | KG | LB | KG | |||
| SLB150 | 1,650 | 0.75 | 1 | 41 | 18.6 | 6 x 18 | 0.5 | 0.2 | 16 | 7.3 |
| SLB200 | 2,200 | 1 | 1 | 60 | 27.3 | 6 x 18 | 0.5 | 0.2 | 16 | 7.3 |
| SLB300 | 3,300 | 1.50 | 1 | 53 | 24.1 | 7.1 x 21.2 | 0.7 | 0.3 | 26 | 11.8 |
| SLB600 | 6,600 | 3 | 1 | 53 | 24.1 | 10 x 30 | 1.5 | 0.7 | 46 | 20.9 |
| SLB1200 | 13,200 | 6 | 2 | 57 | 25.9 | 10 x 30 | 2.9 | 1.3 | 69 | 31.4 |
