Ingersoll Rand PT030-8-SB Push Hook-On Trolley is a 3-metric-ton (6,600-lb) capacity PT Series trolley with solid-bronze wheels for overhead material handling. The standard flange adjustment is 3.9–8 in., allowing the trolley to fit compatible beams within that range. The solid bronze wheel option is specified for maximum spark resistance, while the push hook-on configuration provides manually controlled trolley travel along the beam.
The PT030-8-SB uses cold-formed steel side plates with rail sweeps and drop stops for strength, durability, and load distribution. Its universal wheel tread accommodates flat or tapered beams, while sealed, lubricated-for-life ball bearings provide smoother rolling with less maintenance. The trolley has a 7-in. minimum beam height and a 42-in. minimum curve radius. The PT Series has a 5:1 design factor and is specified for use with both manual and powered hoists.
Type: Push Hook-On Trolley | Series: PT Series | Model: PT030-8-SB | Capacity: 3 Metric Tons (6,600 lb) | Wheel Type: Solid Bronze Alloy | Flange Adjustment: 3.9–8 in. | Minimum Beam Height: 7 in. | Minimum Curve Radius: 42 in. | Design Factor: 5:1 | Standard PT030-8 Weight: 73.2 lb
Features:
- The 5:1 design factor permits the PT Series to be used with both manual and powered hoists.
- Solid bronze alloy wheels provide maximum spark resistance where this characteristic is required.
- Cold-formed steel side plates provide strength, durability, and even load distribution.
- Rail sweeps and drop stops are incorporated into the side-plate construction.
- Rivet-locked wheel axles resist loosening during trolley operation.
- Universal wheel tread is suitable for flat or tapered beams.
- Sealed, lubricated-for-life ball bearings provide smoother rolling with less effort and maintenance.
- Wide hanger shaft assemblies accommodate compatible I-beams, H-beams, and patented track beams up to approximately 8.06 in. / 205 mm wide.
- The hanger shaft has a squared recess that accepts round or squared hook shapes from compatible hoists.
- Shaft extension kits are available separately for standard trolleys requiring an 8–13 in. flange adjustment range.
Made in USA:
Applications:
- Industrial material handling — moving compatible loads up to the 6,600 lb rated capacity along suitable overhead beams.
- Maintenance and MRO — suspending and repositioning compatible manual or powered hoists during equipment service work.
- Fabrication and manufacturing — moving suspended equipment, components, and assemblies along compatible overhead beam systems.
- Workshops and maintenance facilities — providing manually controlled trolley travel for compatible lifting equipment.
- Spark-sensitive material handling — using the solid bronze wheel configuration where maximum spark resistance is required.
- Overhead lifting systems — pairing the trolley with a compatible hoist where the 3 metric ton capacity and 3.9–8 in. flange range meet the installation requirements.
FAQs:
- Q: What is the capacity of the PT030-8-SB?
A: The PT030-8-SB is rated for 3 metric tons, equivalent to 6,600 lb. - Q: What does SB mean in the model number?
A: SB identifies the solid bronze wheel option. Ingersoll Rand specifies solid bronze alloy wheels for maximum spark resistance. - Q: What beam flange width can the PT030-8-SB accommodate?
A: The PT030-8 configuration has a 3.9–8 in. flange adjustment range. - Q: Can this trolley be used with a powered hoist?
A: Yes. The PT Series has a 5:1 design factor and is specified for use with both manual and powered hoists. - Q: What is the minimum beam height?
A: The minimum specified beam height for the PT030-8 is 7 in. - Q: What is the minimum curve radius?
A: The minimum specified curve radius is 42 in.
| SKU | CAPACITY | FLANGE ADJUSTMENT IN |
MIN. BEAM HEIGHT IN |
MIN. CURVE RADIUS IN |
WEIGHT LB |
WIDE FLANGE KIT NO. (ORDER SEPARATE) |
FLANGE ADJUSTMENT IN |
WEIGHT LB |
|
|---|---|---|---|---|---|---|---|---|---|
| LB | METRIC TONS | ||||||||
| STANDARD SERIES | |||||||||
| PT005-8 | 1,100 | 0.50 | 2.6 - 8 | 4 | 36 | 19.7 | PT005-WFK | 8 - 13 | 5.5 |
| PT010-8 | 2,200 | 1 | 3 - 8 | 5 | 36 | 30.7 | PT010-WFK | 8 - 13 | 9.5 |
| PT020-8 | 4,400 | 2 | 3.3 - 8 | 6 | 48 | 60.5 | PT020-WFK | 8 - 13 | 10 |
| PT030-8 | 6,600 | 3 | 3.9 - 8 | 7 | 42 | 73.2 | PT030-WFK | 8 - 13 | 16.3 |
| PT050-8 | 11,000 | 5 | 4.6 - 8 | 8 | 60 | 110.3 | PT050-WFK | 8 - 13 | 24.8 |
| PT100-12 | 22,000 | 10 | 7 - 13 | 10 | 83 | 205 | NA | NA | NA |
| GT010-8-10 | 2,200 | 1 | 3 - 8 | 5 | 36 | 43.7 | PT010-WFK | 8 - 13 | 9.5 |
| GT020-8-10 | 4,400 | 2 | 3.3 - 8 | 6 | 48 | 73.5 | PT020-WFK | 8 - 13 | 10 |
| GT030-8-10 | 6,600 | 3 | 3.9 - 8 | 7 | 42 | 86.2 | PT030-WFK | 8 - 13 | 16.3 |
| GT-050-8-10 | 11,000 | 5 | 4.6 - 8 | 8 | 60 | 123.3 | PT050-WFK | 8 - 13 | 24.8 |
| GT100-12-10 | 22,000 | 10 | 7 - 13 | 10 | 83 | 227 | NA | NA | NA |
| GT200-12 | 44,000 | 20 | 7 - 13 | 12 | 138 | 540 | NA | NA | NA |
