Ingersoll Rand PT030-8 Push Hook-On Trolley is a 3-metric-ton (6,600-lb) capacity PT Series trolley designed to move compatible manual or powered hoists along overhead beams. Its 3.9–8 in. flange adjustment accommodates compatible beam widths, while the 42 in. minimum curve radius supports travel through suitable curved beam sections. The push hook-on design provides manually controlled trolley movement without a separate drive mechanism.
The PT030-8 uses cast iron wheels with a universal tread for flat or tapered beams and sealed, Lube-for-Life ball bearings for smoother rolling with less maintenance. Cold-formed steel side plates incorporate rail sweeps and drop stops for strength and load distribution, while rivet-locked wheel axles are designed to resist loosening. The trolley has a 7 in. minimum beam height, a 5:1 design factor, and a catalog-listed 73.2 lb weight. The manufacturer specifies the PT Series for use with both manual and powered hoists.
Type: Push Hook-On Trolley | Series: PT Series | Model: PT030-8 | Capacity: 3 Metric Tons (6,600 lb) | Wheel Type: Cast Iron | Flange Adjustment: 3.9–8 in. | Minimum Beam Height: 7 in. | Minimum Curve Radius: 42 in. | Design Factor: 5:1 | Weight: 73.2 lb
Features:
- The 5:1 design factor permits use with both manual and powered hoists.
- Cold-formed steel side plates provide strength, durability, and even load distribution.
- Rail sweeps and drop stops are incorporated into the side-plate construction.
- Rivet-locked wheel axles resist loosening during trolley operation.
- Cast iron wheels use a universal tread for either flat or tapered beams.
- Sealed, Lube-for-Life ball bearings provide smoother rolling with less effort and maintenance.
- Wide hanger shaft assemblies accommodate compatible I-beams, H-beams, and patented track beams up to approximately 8.06 in. / 205 mm wide.
- PT Series hanger shafts are designed to accept compatible hoists from different brands and accommodate round or squared hook shapes.
- Shaft extension kits are available separately for standard trolleys requiring an 8–13 in. flange adjustment range.
- The trolley is painted black for universal coordination with hoists of different colors.
Made in USA:
Applications:
- Industrial material handling — moving compatible loads up to the 6,600 lb rated capacity along suitable overhead beams.
- Maintenance and MRO — suspending and repositioning compatible manual or powered hoists during equipment service work.
- Fabrication and manufacturing — moving suspended components, equipment, and assemblies along compatible overhead beam systems.
- Workshops and maintenance facilities — providing manually controlled trolley travel for compatible lifting equipment.
- Overhead lifting systems — pairing the trolley with a compatible hoist where the 3 metric ton capacity and 3.9–8 in. flange range meet installation requirements.
FAQs:
- Q: What is the capacity of the PT030-8?
A: The PT030-8 is rated for 3 metric tons, equivalent to 6,600 lb. - Q: What beam flange width can the PT030-8 accommodate?
A: The standard PT030-8 has a 3.9–8 in. flange adjustment range. - Q: What type of wheels does the standard PT030-8 use?
A: The standard PT030-8 uses cast iron wheels with a universal tread for flat or tapered beams. - Q: Can the PT030-8 be used with a powered hoist?
A: Yes. The PT Series has a 5:1 design factor and is specified for use with both manual and powered hoists. - Q: What is the minimum beam height?
A: The minimum specified beam height for the PT030-8 is 7 in. - Q: What is the minimum curve radius?
A: The minimum specified curve radius is 42 in. - Q: Is a wider flange adjustment available?
A: Yes. The manufacturer lists the PT030-WFK wide-flange kit separately for an 8–13 in. flange adjustment. The kit is not included with the PT030-8.
| SKU | CAPACITY | FLANGE ADJUSTMENT IN |
MIN. BEAM HEIGHT IN |
MIN. CURVE RADIUS IN |
WEIGHT LB |
WIDE FLANGE KIT NO. (ORDER SEPARATE) |
FLANGE ADJUSTMENT IN |
WEIGHT LB |
|
|---|---|---|---|---|---|---|---|---|---|
| LB | METRIC TONS | ||||||||
| STANDARD SERIES | |||||||||
| PT005-8 | 1,100 | 0.50 | 2.6 - 8 | 4 | 36 | 19.7 | PT005-WFK | 8 - 13 | 5.5 |
| PT010-8 | 2,200 | 1 | 3 - 8 | 5 | 36 | 30.7 | PT010-WFK | 8 - 13 | 9.5 |
| PT020-8 | 4,400 | 2 | 3.3 - 8 | 6 | 48 | 60.5 | PT020-WFK | 8 - 13 | 10 |
| PT030-8 | 6,600 | 3 | 3.9 - 8 | 7 | 42 | 73.2 | PT030-WFK | 8 - 13 | 16.3 |
| PT050-8 | 11,000 | 5 | 4.6 - 8 | 8 | 60 | 110.3 | PT050-WFK | 8 - 13 | 24.8 |
| PT100-12 | 22,000 | 10 | 7 - 13 | 10 | 83 | 205 | NA | NA | NA |
| GT010-8-10 | 2,200 | 1 | 3 - 8 | 5 | 36 | 43.7 | PT010-WFK | 8 - 13 | 9.5 |
| GT020-8-10 | 4,400 | 2 | 3.3 - 8 | 6 | 48 | 73.5 | PT020-WFK | 8 - 13 | 10 |
| GT030-8-10 | 6,600 | 3 | 3.9 - 8 | 7 | 42 | 86.2 | PT030-WFK | 8 - 13 | 16.3 |
| GT-050-8-10 | 11,000 | 5 | 4.6 - 8 | 8 | 60 | 123.3 | PT050-WFK | 8 - 13 | 24.8 |
| GT100-12-10 | 22,000 | 10 | 7 - 13 | 10 | 83 | 227 | NA | NA | NA |
| GT200-12 | 44,000 | 20 | 7 - 13 | 12 | 138 | 540 | NA | NA | NA |
Looking for more information about Ingersoll Rand Push Trolley? Click here to view the Catalog
For help selecting the correct Ingersoll Rand Push Trolleys for your assembly application, call (800) 608-5210 or email info@intlairtool.com
