Ingersoll Rand PT020-8-SB Push Hook-On Trolley provides a 2 metric ton (4,400 lb) capacity for moving compatible manual or powered hoists along overhead beams. This configuration uses solid bronze alloy wheels, specified by Ingersoll Rand for maximum spark resistance, while the standard flange adjustment accommodates beam flanges from 3.3 to 8 in. The trolley's push hook-on configuration provides manually controlled beam travel without a separate drive mechanism.
The PT020-8-SB is built around cold-formed steel side plates with rail sweeps and drop stops for load distribution and trolley protection. Its universal wheel tread fits flat or tapered beams, while sealed, Lube-for-Life ball bearings provide smoother rolling with less maintenance. The trolley has a 6 in. minimum beam height and a 48 in. minimum curve radius. A 5:1 design factor permits use with compatible manual or powered hoists. The manufacturer lists the standard PT020-8 weight as 60.5 lb; a separate weight for the solid-bronze-wheel configuration is not provided.
Type: Push Hook-On Trolley | Series: PT Series | Model: PT020-8-SB | Capacity: 2 Metric Tons (4,400 lb) | Wheel Type: Solid Bronze Alloy | Flange Adjustment: 3.3–8 in. | Minimum Beam Height: 6 in. | Minimum Curve Radius: 48 in. | Design Factor: 5:1 | Standard PT020-8 Weight: 60.5 lb
Features:
- The 5:1 design factor permits use with both manual and powered hoists.
- Solid bronze alloy wheels provide maximum spark resistance where this characteristic is required.
- Cold-formed steel side plates provide strength, durability, and even load distribution.
- Rail sweeps and drop stops are incorporated into the side-plate construction.
- Universal wheel tread fits either flat or tapered beams.
- Wheels run on sealed, Lube-for-Life ball bearings for smoother rolling with less effort and maintenance.
- Wide hanger shaft capabilities allow the trolley to fit compatible S-beams and patented track beams; extension shaft kits are available separately.
- The PT Series is compatible with manual and powered hoists and is specified to meet pertinent U.S. ASME/ANSI and CMAA, Canadian, and European standards.
- The trolley is painted black for coordination with hoists of different colors.
Made in USA:
Applications:
- Industrial material handling — moving compatible loads up to the 4,400 lb rated capacity along suitable overhead beams.
- Maintenance and MRO — suspending and repositioning compatible manual or powered hoists for equipment service work.
- Fabrication and manufacturing — moving suspended components, assemblies, and materials along compatible I-beams, H-beams, or track beams.
- Overhead lifting systems — pairing the trolley with a compatible hoist where the 2 metric ton capacity and 3.3–8 in. flange range are suitable.
- Spark-sensitive material handling — using the solid bronze wheel configuration where maximum spark resistance is required.
FAQs:
- Q: What is the capacity of the PT020-8-SB?
A: The PT020-8-SB is rated for 2 metric tons, equivalent to 4,400 lb. - Q: What does SB mean in the model number?
A: SB identifies the solid bronze wheel option. Ingersoll Rand specifies solid bronze alloy wheels for maximum spark resistance. - Q: What beam flange width can the PT020-8-SB accommodate?
A: The PT020-8 configuration has a 3.3–8 in. flange adjustment range. - Q: Can the PT020-8-SB be used with a powered hoist?
A: Yes. The PT Series has a 5:1 design factor and is specified for use with both manual and powered hoists. - Q: What is the minimum beam height?
A: The minimum specified beam height for the PT020-8 is 6 in. - Q: What is the minimum curve radius?
A: The minimum specified curve radius is 48 in. - Q: What does the published 60.5 lb weight refer to?
A: The catalog lists 60.5 lb for the standard PT020-8. It does not provide a separate weight for the PT020-8-SB solid-bronze configuration.
| SKU | CAPACITY | FLANGE ADJUSTMENT IN |
MIN. BEAM HEIGHT IN |
MIN. CURVE RADIUS IN |
WEIGHT LB |
WIDE FLANGE KIT NO. (ORDER SEPARATE) |
FLANGE ADJUSTMENT IN |
WEIGHT LB |
|
|---|---|---|---|---|---|---|---|---|---|
| LB | METRIC TONS | ||||||||
| STANDARD SERIES | |||||||||
| PT005-8 | 1,100 | 0.50 | 2.6 - 8 | 4 | 36 | 19.7 | PT005-WFK | 8 - 13 | 5.5 |
| PT010-8 | 2,200 | 1 | 3 - 8 | 5 | 36 | 30.7 | PT010-WFK | 8 - 13 | 9.5 |
| PT020-8 | 4,400 | 2 | 3.3 - 8 | 6 | 48 | 60.5 | PT020-WFK | 8 - 13 | 10 |
| PT030-8 | 6,600 | 3 | 3.9 - 8 | 7 | 42 | 73.2 | PT030-WFK | 8 - 13 | 16.3 |
| PT050-8 | 11,000 | 5 | 4.6 - 8 | 8 | 60 | 110.3 | PT050-WFK | 8 - 13 | 24.8 |
| PT100-12 | 22,000 | 10 | 7 - 13 | 10 | 83 | 205 | NA | NA | NA |
| GT010-8-10 | 2,200 | 1 | 3 - 8 | 5 | 36 | 43.7 | PT010-WFK | 8 - 13 | 9.5 |
| GT020-8-10 | 4,400 | 2 | 3.3 - 8 | 6 | 48 | 73.5 | PT020-WFK | 8 - 13 | 10 |
| GT030-8-10 | 6,600 | 3 | 3.9 - 8 | 7 | 42 | 86.2 | PT030-WFK | 8 - 13 | 16.3 |
| GT-050-8-10 | 11,000 | 5 | 4.6 - 8 | 8 | 60 | 123.3 | PT050-WFK | 8 - 13 | 24.8 |
| GT100-12-10 | 22,000 | 10 | 7 - 13 | 10 | 83 | 227 | NA | NA | NA |
| GT200-12 | 44,000 | 20 | 7 - 13 | 12 | 138 | 540 | NA | NA | NA |
