Ingersoll Rand PT020-8 Push Hook-On Trolley is a 2 metric ton (4,400 lb) capacity PT Series trolley designed for use with compatible manual or powered hoists. Its 3.3–8 in. flange adjustment accommodates a range of compatible beam widths, while the 48 in. minimum curve radius supports travel through compatible curved beam sections. The push hook-on design provides manually controlled trolley movement along the beam.
The PT020-8 uses cast iron wheels with a universal tread for flat or tapered beams, along with sealed, Lube-for-Life ball bearings for smoother rolling with less effort and maintenance. Cold-formed steel side plates provide strength, durability, and load distribution, with rail sweeps and drop stops incorporated into the design. The trolley has a 6 in. minimum beam height, a 5:1 design factor, and a listed 60.5 lb weight. The manufacturer specifies the PT Series for use with both manual and powered hoists.
Type: Push Hook-On Trolley | Series: PT Series | Model: PT020-8 | Capacity: 2 Metric Tons (4,400 lb) | Wheel Type: Cast Iron | Flange Adjustment: 3.3–8 in. | Minimum Beam Height: 6 in. | Minimum Curve Radius: 48 in. | Design Factor: 5:1 | Weight: 60.5 lb
Features:
- The 5:1 design factor allows use with both manual and powered hoists.
- Cast iron wheels provide a durable wheel material for standard trolley applications.
- Universal wheel tread fits either flat or tapered beams.
- Cold-formed steel side plates provide strength, durability, and even load distribution.
- Rail sweeps and drop stops are incorporated into the side-plate construction.
- Sealed, Lube-for-Life ball bearings provide smoother rolling with less effort and maintenance.
- Wider hanger shaft capabilities allow the standard trolley to fit a broad range of compatible S-beams and patented track beams.
- Extension shaft kits are stocked separately for applications requiring a wider flange adjustment.
- The PT Series is designed for compatibility with hoists from different brands.
- The trolley is painted black for coordination with hoists of different colors.
Made in USA:
Applications:
- Industrial material handling — moving compatible loads up to the 4,400 lb rated capacity along suitable overhead beams.
- Maintenance and MRO — suspending and repositioning compatible manual or powered hoists during equipment service work.
- Fabrication and manufacturing — moving suspended components and assemblies along compatible overhead beam systems.
- Workshop lifting systems — providing manually controlled trolley travel for compatible hoists.
- Overhead beam handling — supporting compatible lifting equipment where the 3.3–8 in. flange range and 48 in. curve radius meet the installation requirements.
FAQs:
- Q: What is the capacity of the PT020-8?
A: The PT020-8 is rated for 2 metric tons, equivalent to 4,400 lb. - Q: What beam flange width can the PT020-8 accommodate?
A: The standard PT020-8 has a 3.3–8 in. flange adjustment range. - Q: What type of wheels does the standard PT020-8 use?
A: The standard PT020-8 uses cast iron wheels with a universal tread for flat or tapered beams. - Q: Can the PT020-8 be used with a powered hoist?
A: Yes. The PT Series has a 5:1 design factor and is specified for use with both manual and powered hoists. - Q: What is the minimum beam height?
A: The minimum specified beam height for the PT020-8 is 6 in. - Q: What is the minimum curve radius?
A: The minimum specified curve radius is 48 in. - Q: Is a wider flange adjustment available?
A: Yes. The manufacturer lists the PT020-WFK wide-flange kit separately, providing an 8–13 in. flange adjustment. The kit is not included with the standard PT020-8.
| SKU | CAPACITY | FLANGE ADJUSTMENT IN |
MIN. BEAM HEIGHT IN |
MIN. CURVE RADIUS IN |
WEIGHT LB |
WIDE FLANGE KIT NO. (ORDER SEPARATE) |
FLANGE ADJUSTMENT IN |
WEIGHT LB |
|
|---|---|---|---|---|---|---|---|---|---|
| LB | METRIC TONS | ||||||||
| STANDARD SERIES | |||||||||
| PT005-8 | 1,100 | 0.50 | 2.6 - 8 | 4 | 36 | 19.7 | PT005-WFK | 8 - 13 | 5.5 |
| PT010-8 | 2,200 | 1 | 3 - 8 | 5 | 36 | 30.7 | PT010-WFK | 8 - 13 | 9.5 |
| PT020-8 | 4,400 | 2 | 3.3 - 8 | 6 | 48 | 60.5 | PT020-WFK | 8 - 13 | 10 |
| PT030-8 | 6,600 | 3 | 3.9 - 8 | 7 | 42 | 73.2 | PT030-WFK | 8 - 13 | 16.3 |
| PT050-8 | 11,000 | 5 | 4.6 - 8 | 8 | 60 | 110.3 | PT050-WFK | 8 - 13 | 24.8 |
| PT100-12 | 22,000 | 10 | 7 - 13 | 10 | 83 | 205 | NA | NA | NA |
| GT010-8-10 | 2,200 | 1 | 3 - 8 | 5 | 36 | 43.7 | PT010-WFK | 8 - 13 | 9.5 |
| GT020-8-10 | 4,400 | 2 | 3.3 - 8 | 6 | 48 | 73.5 | PT020-WFK | 8 - 13 | 10 |
| GT030-8-10 | 6,600 | 3 | 3.9 - 8 | 7 | 42 | 86.2 | PT030-WFK | 8 - 13 | 16.3 |
| GT-050-8-10 | 11,000 | 5 | 4.6 - 8 | 8 | 60 | 123.3 | PT050-WFK | 8 - 13 | 24.8 |
| GT100-12-10 | 22,000 | 10 | 7 - 13 | 10 | 83 | 227 | NA | NA | NA |
| GT200-12 | 44,000 | 20 | 7 - 13 | 12 | 138 | 540 | NA | NA | NA |
