Ingersoll Rand 8611-A Non-Reversible Multi-Vane Air Motor | Planetary Gear | 0.10 HP | 5,000 RPM | 0.42 (ft-lbs) Stall Torque | Single Gear Reduction

Designed for equipment and machinery requiring compact, higher-speed pneumatic rotary power, the Ingersoll Rand 8611-A Non-Reversible Multi-Vane Air Motor delivers 0.10 HP with a 5,000 RPM free speed. Its 3/8" keyed spindle provides a defined connection for compatible driven components, while the single gear reduction supports the motor's higher operating-speed configuration.

Under load at maximum horsepower, the 8611-A operates at 2,500 RPM and produces 0.21 lb-ft (0.3 Nm) of torque, with stall torque rated at 0.42 lb-ft (0.6 Nm). Free-speed air consumption is 9.5 SCFM (4.5 L/s), providing an important reference when sizing the compressed-air supply for the installation.

Type: Multi-Vane Air Motor | Model: 8611-A | Configuration: Non-Reversible | Power: 0.10 HP | Spindle: 3/8" Keyed | Free Speed: 5,000 RPM | Load Speed at Max. HP: 2,500 RPM | Torque Output at Max. HP: 0.21 lb-ft (0.3 Nm) | Stall Torque: 0.42 lb-ft (0.6 Nm) | Air Consumption at Free Speed: 9.5 SCFM (4.5 L/s) | Sound Level at Free Speed: 80 dB(A) | Weight: 0.80 lb (0.36 kg) | Gear Reduction: Single

Features:

• Multi-vane pneumatic design provides rotary power for compatible machinery, fixtures, and equipment.
• 5,000 RPM free speed supports applications requiring faster rotary output from a compact air motor.
• 2,500 RPM load speed at maximum horsepower provides a useful reference for matching the motor to operating requirements under load.
• 3/8" keyed spindle provides a defined mechanical interface for compatible driven components.
• Single gear reduction supports the higher-speed output characteristics of this model.
• Non-reversible configuration provides single-direction motor operation.
• 0.80 lb (0.36 kg) weight supports integration where equipment weight is an important design consideration.
• 9.5 SCFM (4.5 L/s) free-speed air consumption helps with compressed-air system planning.

Made in USA:

Applications:

• Machinery requiring compact, higher-speed pneumatic rotary power.
• Production equipment and fixtures designed for single-direction motor operation.
• Automation systems requiring a 3/8" keyed spindle connection.
• Mechanical equipment where the specified speed and torque characteristics match the driven load.
• Compressed-air-powered systems where a lightweight pneumatic motor is appropriate for the equipment design.

FAQs:

• Q: What is the operating speed of the Ingersoll Rand 8611-A?
  A: The 8611-A has a free speed of 5,000 RPM. At maximum horsepower, the manufacturer specifies a load speed of 2,500 RPM.
• Q: How much torque does the 8611-A produce?
  A: Torque output at maximum horsepower is 0.21 lb-ft (0.3 Nm), while stall torque is rated at 0.42 lb-ft (0.6 Nm).
• Q: What type of spindle does the 8611-A use?
  A: The motor uses a 3/8" keyed spindle. The driven component and connection arrangement should be compatible with this spindle configuration.
• Q: How much compressed air does the 8611-A consume?
  A: Air consumption at free speed is specified at 9.5 SCFM (4.5 L/s). This value should be considered when sizing the air supply for the motor.
• Q: How does the 8611-A differ from the 8610-A?
  A: Both are non-reversible 0.10 HP models with 3/8" keyed spindles, but their speed, torque, and gearing differ. The 8611-A uses single gear reduction and operates at 5,000 RPM free speed, while the 8610-A uses double gear reduction and operates at 1,000 RPM, providing different speed and torque characteristics for matching the motor to the driven load.
