Ingersoll Rand 8266-A17-2 Self-Feed Offset Drill | 3/16" Capacity | 50 HP | 1,700 RPM | Double Gear Reduction

Designed for precision production drilling, the Ingersoll Rand 8266-A17-2 self-feed offset drill combines a 3/16" drilling capacity, 1,700 RPM free speed, and double gear reduction to provide controlled, repeatable drilling performance for demanding manufacturing environments. Its integrated self-feed mechanism automatically advances the drill into the workpiece, helping produce consistent hole quality while reducing operator fatigue during repetitive drilling operations.

The offset head design improves accessibility when drilling near flanges, structural members, and other obstructions where conventional inline drills have limited clearance. Built for continuous-duty industrial service, the 8266-A17-2 delivers dependable pneumatic performance for aerospace, transportation, fabrication, and general manufacturing applications that require accurate hole placement and repeatable production results.

Type: Self-Feed Offset Drill | Drilling Capacity: 3/16 in. | Free Speed: 1,700 RPM | Gear Reduction: Double Gear Reduction

Features:

• Self-feed mechanism automatically advances the drill for consistent hole quality and reduced operator effort.
• Offset head configuration improves access when drilling near edges, flanges, and structural obstructions.
• 1,700 RPM free speed provides controlled drilling for precision production applications.
• Double gear reduction delivers smooth, controlled power transmission during demanding drilling operations.
• Designed for repetitive manufacturing environments requiring reliable drilling consistency.
• Pneumatic operation supports continuous-duty industrial production with dependable performance.
• Suitable for automated and semi-automated drilling processes where repeatability is essential.

Applications:

• Production drilling in aerospace and aircraft manufacturing.
• Industrial fabrication requiring accurate, repeatable hole drilling.
• Transportation equipment and vehicle component manufacturing.
• Assembly operations where automatic feed improves productivity and consistency.
• General manufacturing applications requiring offset-head accessibility and controlled feed rates.

FAQs:

• Q: What is the advantage of a self-feed drill?
  A: A self-feed drill automatically advances into the workpiece at a controlled rate, helping improve hole consistency, reduce operator fatigue, and increase production efficiency.
• Q: Why is an offset head beneficial?
  A: The offset head allows the drill to reach locations near flanges, edges, and structural obstructions where straight drills may not have sufficient clearance.
• Q: What is the purpose of the double gear reduction?
  A: Double gear reduction provides controlled power transmission for smooth, consistent drilling performance in repetitive industrial applications.
• Q: What industries commonly use the 8266-A17-2?
  A: This drill is well suited for aerospace manufacturing, industrial fabrication, transportation equipment production, and other applications requiring accurate, repeatable drilling.

NON RETURNABLE. MADE TO ORDER.

Looking for more information about Ingersoll Rand Self-Feed Air Drill? Click here to view the Catalog

For help choosing the correct Ingersoll Rand Self-Feed Air Drills for your application, please call (800) 608-5210 or email info@intlairtool.com
