Ingersoll Rand 7800-B Non-Reversible Air Power Motor is designed to provide dependable pneumatic rotary power for industrial machinery requiring high-speed operation in a single direction. Part of the 2200 Series, this air motor delivers 0.85 HP with a free speed of 18,000 RPM. Equipped with a single gear reduction, the 7800-B is well suited for OEM equipment, high-speed processing machinery, automated production systems, and industrial applications where compressed-air power is preferred over electric motors.
The 7800-B develops a 1.00 lb-ft stall torque, representing the maximum torque produced when the output shaft is prevented from rotating. Its non-reversible design provides consistent rotation in one direction, while the single gear reduction offers an efficient balance of high rotational speed and compact power transmission for demanding industrial environments.
Type: Air Power Motor | Model: 7800-B | Series: 2200 Series | Rotation: Non-Reversible | Gear Reduction: Single Gear Reduction | Power: 0.85 HP | Free Speed: 18,000 RPM | Stall Torque: 1.00 lb-ft
Features:
- Non-reversible air motor provides dependable single-direction pneumatic rotary power.
- 2200 Series design supports a variety of industrial OEM and replacement applications.
- Single gear reduction provides efficient power transmission while maintaining high rotational speed.
- 0.85 HP output is suitable for demanding pneumatic drive applications.
- 18,000 RPM free speed supports high-speed industrial equipment and rotary processes.
- 1.00 lb-ft stall torque provides a manufacturer-published reference for evaluating maximum torque capability.
- Compressed-air operation eliminates the need for electrical power at the motor.
Made in USA:
Applications:
- OEM machinery requiring high-speed pneumatic rotary power.
- Automated manufacturing and production equipment.
- Industrial processing and assembly systems.
- High-speed spindle and rotary drive applications.
- Replacement applications where the published motor specifications match the original equipment.
FAQs:
- Q: Is the Ingersoll Rand 7800-B reversible?
A: No. This model is a non-reversible air motor designed for continuous rotation in a single direction. - Q: What does single gear reduction mean?
A: Single gear reduction uses one reduction stage to transmit power, providing a balance between high rotational speed and usable output torque. - Q: What is the rated free speed?
A: The manufacturer specifies a free speed of 18,000 RPM. - Q: What does stall torque indicate?
A: Stall torque is the maximum torque the motor can produce when the output shaft is prevented from rotating. - Q: What should be verified before installation?
A: Confirm horsepower, free speed, rotation direction, gear reduction, shaft dimensions, mounting arrangement, and compressed-air requirements using the Ingersoll Rand Air Motor Catalog before installation.
| SKU | Spindle | R.P.M. | Torque | Air Consumption at Free Speed | Sound Level at Free Speed | Weight | Gear Reduction | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Free Speed | Load Speed at Max. Hp | Stall | Output | SCFM | L/s | lbs | kg | ||||||
| (ft-lbs) | Nm | (ft-lbs) | Nm | dB(A) | |||||||||
| Non-Reversible - 0.85 HP | |||||||||||||
| 7800-B | 1/2" Keyed | 18,000 | 9,000 | 1.00 | 1.4 | 0.50 | 0.68 | 41.7 | 19.7 | 78 | 4.24 | 1.91 | Single |
| 7801-B | 1/2" Keyed | 4,600 | 2,400 | 4.00 | 5.5 | 1.86 | 2.5 | 41.7 | 19.7 | 78 | 4.24 | 1.91 | Single |
| 7802-B | 1/2" Keyed | 2,500 | 1,300 | 7.50 | 10.3 | 3.43 | 4.7 | 41.7 | 19.7 | 78 | 4.24 | 1.91 | Single |
| 7803-B | 1/2" Keyed | 1,200 | 600 | 16.00 | 21.9 | 7.44 | 10.2 | 41.7 | 19.7 | 78 | 5.17 | 2.33 | Double |
| 7804-B | 1/2" Keyed | 650 | 320 | 30.00 | 41.2 | 13.95 | 19.1 | 41.7 | 19.7 | 78 | 5.17 | 2.33 | Double |
| 7805-B | 1/2" Keyed | 350 | 170 | 55.00 | 75.5 | 26.25 | 36.0 | 41.7 | 19.7 | 78 | 5.17 | 2.33 | Double |
| 7812-B | 1/2"-20 Th’d. | 350 | 170 | 55.00 | 75.5 | 26.25 | 36.0 | 41.7 | 19.7 | 78 | 5.17 | 2.33 | Double |
| 7813-B | 1/2"-20 Th’d. | 650 | 320 | 30.00 | 41.2 | 13.95 | 19.1 | 41.7 | 19.7 | 78 | 5.17 | 2.33 | Double |
| 7814-B | 1/2"-20 Th’d. | 18,000 | 9,000 | 1.00 | 1.4 | 0.50 | 0.68 | 41.7 | 19.7 | 78 | 4.24 | 1.91 | Single |
| 7815-B | 1/2"-20 Th’d. | 1,200 | 600 | 16.00 | 21.9 | 7.44 | 10.2 | 41.7 | 19.7 | 78 | 5.17 | 2.33 | Double |
| 7816-B | 1/2"-20 Th’d. | 4,600 | 2,400 | 4.00 | 5.5 | 1.86 | 2.5 | 41.7 | 19.7 | 78 | 4.24 | 1.91 | Single |
| 7817-B | 1/2"-20 Th’d. | 2,500 | 1,300 | 7.50 | 10.3 | 3.43 | 4.7 | 41.7 | 19.7 | 78 | 4.24 | 1.91 | Single |
| Reversible - 0.70 HP | |||||||||||||
| 7806-B | 1/2" Keyed | 13,500 | 7,000 | 1.00 | 1.4 | 0.52 | 0.71 | 37.3 | 17.6 | 85* | 4.24 | 1.91 | Single |
| 7807-B | 1/2" Keyed | 3,400 | 1,800 | 4.00 | 5.5 | 2.04 | 2.8 | 37.3 | 17.6 | 85* | 4.24 | 1.91 | Single |
| 7808-B | 1/2" Keyed | 1,800 | 1,000 | 7.40 | 10.2 | 3.67 | 5.0 | 37.3 | 17.6 | 85* | 4.24 | 1.91 | Single |
| 7809-B | 1/2" Keyed | 850 | 450 | 15.50 | 21.3 | 8.16 | 11.2 | 37.3 | 17.6 | 85* | 5.17 | 2.33 | Double |
| 7810-B | 1/2" Keyed | 450 | 240 | 29.00 | 39.8 | 15.30 | 21.0 | 37.3 | 17.6 | 85* | 5.17 | 2.33 | Double |
| 7811-B | 1/2" Keyed | 250 | 130 | 54.00 | 74.0 | 28.20 | 38.7 | 37.3 | 17.6 | 85* | 5.17 | 2.33 | Double |
Looking for more information about Ingersoll Rand Air Power Motor? Click here to view the Catalog
For help selecting the correct Ingersoll Rand Air Power Motors for your assembly application, call (800) 608-5210 or email info@intlairtool.com
