Ingersoll Rand 7796AL-2R45-R20 ARO 7700 Series and 7790 Series Spark-Resistant Link Chain Hoist is engineered for Division 1 hazardous applications where, under normal operating conditions, the atmosphere may contain flammable gases, dust, or other combustible materials. Built to meet the demands of hazardous industrial environments, this hoist delivers safe, reliable performance without compromising productivity. Specifically designed for continuous heavy-duty industrial use, the 7700 and 7790 Series spark-resistant hoist handles loads ranging from 500 lbs to 3,000 lbs. It is available with a bronze top hook or trolley adapter suspension, providing installation flexibility for a wide range of lifting applications. The hoist comes standard with 10 ft of lift and includes 6 ft pendant control or 6 ft pull-chain control, ensuring precise, controlled operation in demanding and safety-critical settings.
Type: Chain Hoist | Series: ARO Series | Capacity (ton): 0.68 | Capacity (lbs.): 1500 | Lift (ft): 45 | Pendent Control Drop (ft): 20 | Control: Pendent Control | Top Suspension: Bronze Snap Hook | Bottom Suspension: Bronze Hook
Features:
- Stainless steel load chain and solid bronze hooks prevent accidental sparking
- Pendent control handles, when ordered, are covered with an industrial-grade vinyl grip; pull-chain controls come standard with zinc-plated pull chain
- Hoist capacities are reduced, and speed adjustments are locked into place to maximize chain life
- Trolley models are supplied with bronze wheels
- Made In USA
Looking for more information about Ingersoll Rand Chain Hoist? Click here to view the Catalog.
Need more feet of chain or a longer pendant hose? How about a motorized trolley? Give us a call at 1-800-608-5210 or email info@intlairtool.com. We can help!
- Type
- Air Chain Hoist
- Series
- ARO Series
- Capacity (tons)
- 0.68
- Capacity (lbs)
- 1500
- Lift (ft.)
- 45
- Drop (ft.)
- 20
- Control
- Pendent Control
- Top Suspension
- Bronze Snap Hook
- Bottom Suspension
- Bronze Hook
- Chain Falls
- 1
- Hook Mount Headroom (in.)
- 18.9
- Trolley Mount Headroom (in.)
- 15
- Lifting Speed Rated Load (ft/min)
- 16
- Lifting Speed Rated Load (m/min)
- 4.9
- Lifting Speed No Load (ft/min)
- 26
- Lifting Speed No Load (m/min)
- 7.6
- Lowering Speed Rated Load (ft/min)
- 16
- Lowering Speed Rated Load (m/min)
- 4.9
- Lowering Speed No Load (ft/min)
- 12
- Lowering Speed No Load (m/min)
- 3.7
- Chain Size
- 0.312 x 0.858
