Ingersoll Rand 7776E-2C20-C16U ARO Series Air Chain Hoist | 1 Ton Capacity | 20 ft Lift | 16 ft Drop | Steel Snap Hook | Pendent Control

Designed for demanding industrial lifting applications, the Ingersoll Rand 7776E-2C20-C16U ARO Series Air Chain Hoist provides a 2,200 lb (1 Metric Ton) lifting capacity with a 20 ft lift and 16 ft Pendent drop. Powered by compressed air, this pneumatic chain hoist delivers dependable lifting performance without electrical power, making it well suited for manufacturing, assembly, maintenance, and production environments requiring continuous-duty operation and precise load positioning.

This configuration features Pendent control, steel snap hooks, and a canvas chain container for safe chain storage during operation. The ARO 7776E Series utilizes a planetary gear transmission, a powerful self-cooling air motor, and a self-adjusting, spring-applied, air-released disc brake to provide reliable lifting performance while securely holding suspended loads.

Type: Air Chain Hoist | Series: ARO 7700 Series | Model: 7776E-2C20-C16U | SKU: 7776E-2C20-C16U | Capacity: 2,200 lb (1 Metric Ton) | Lift: 20 ft | Pendent Drop: 16 ft | Control: Pendent Control | Top Suspension: Steel Snap Hook | Bottom Suspension: Steel Snap Hook | Chain Container: Canvas | Chain Falls: 2 | Rated Lift Speed: 21 ft/min (6.4 m/min) | No-Load Lift Speed: 36 ft/min (11 m/min) | Rated Lowering Speed: 56 ft/min (17.1 m/min) | No-Load Lowering Speed: 30 ft/min (9.1 m/min) | Hook Mount Headroom: 21.7 in (551 mm) | Trolley Mount Headroom: 20.5 in (521 mm) | Chain Size: 0.25 x 0.75 in | Chain Weight: 0.6 lb/ft (0.3 kg/ft) | Working Pressure: 70–100 PSI (5–7 bar) | Air Consumption @ Rated Load: 70 CFM (1.98 m³/min) | Air Inlet: 1/2 in NPT

Features:

• 2,200 lb (1 metric ton) lifting capacity for demanding industrial material handling applications.
• 20 ft lift accommodates applications requiring greater vertical lifting distance.
• 16 ft Pendent drop provides comfortable operator access from floor level.
• Canvas chain container keeps excess load chain safely contained during operation.
• Steel snap hooks provide secure attachment at both suspension and load connection points.
• Planetary gear transmission delivers efficient power transfer and dependable lifting performance.
• Self-adjusting, spring-applied, air-released disc brake securely holds suspended loads if air supply is interrupted.
• 100% duty cycle supports continuous industrial operation.

Made in USA:

Applications:

• Manufacturing and production facilities.
• Assembly line material handling.
• Industrial maintenance operations.
• Machine shops and fabrication facilities.
• Warehouses and overhead lifting systems requiring extended lift height.

FAQs:

• Q: What is the lifting capacity of the 7776E-2C20-C16U?
  A: This model is rated to lift 2,200 lb (1 metric ton).
• Q: What does the "U" suffix indicate?
  A: The "U" designation identifies the hoist as being supplied with a canvas chain container.
• Q: How many chain falls does this hoist use?
  A: This 1-ton model utilizes a two-fall load chain configuration.
• Q: What operating air pressure is required?
  A: The recommended operating pressure is 70–100 PSI (5–7 bar).
• Q: What type of suspension does this model use?
  A: This configuration includes steel snap hooks for both the upper suspension and lower load hook.
