Ingersoll Rand 7770E-1C10-C6S ARO Series Air Chain Hoist | 1/8 Ton Capacity | 10 ft Lift | 6 ft Drop | Steel Snap Hook | Pull Chain Control

Designed for dependable light-duty material handling in manufacturing facilities, maintenance departments, assembly workstations, and industrial production environments, the Ingersoll Rand 7770E-1C10-C6S ARO Series Air Chain Hoist delivers a 275 lb (125 kg / 0.125 Metric Ton) lifting capacity with a 10 ft lift and 6 ft control drop. Powered by compressed air, this compact pneumatic hoist provides fast lifting speeds, smooth operation, and precise load handling, making it ideal for repetitive lifting applications where compressed air is readily available.

Part of the Ingersoll Rand ARO 7700 Series, this air chain hoist features a pull chain control that allows operators to manually raise and lower loads using a durable control chain. Its lightweight construction, steel snap hook, and compact design simplify installation while providing dependable performance for lifting tools, fixtures, components, and other light industrial loads.

Type: Air Chain Hoist | Series: ARO 7700 Series | Model: 7770E-1C10-C6S | Capacity: 275 lb (125 kg / 0.125 Metric Ton) | Lift: 10 ft | Control Drop: 6 ft | Control Type: Pull Chain Control | Bottom Hook: Steel Snap Hook | Chain Falls: 1 | Rated Lift Speed: 110 ft/min (33.5 m/min) | No-Load Lift Speed: 192 ft/min (58.5 m/min) | Rated Lowering Speed: 275 ft/min (83.8 m/min) | No-Load Lowering Speed: 159 ft/min (48.5 m/min) | Hook Mount Headroom: 17 in (431.8 mm) | Trolley Mount Headroom: 16.9 in (429.3 mm) | Chain Size: 0.25 × 0.75 in | Chain Weight: 0.6 lb/ft (0.3 kg/ft) | Net Weight (10 ft Lift): 41 lb (18.6 kg)

Features:

• 275 lb (125 kg / 0.125 Metric Ton) lifting capacity for handling lightweight industrial equipment, tools, fixtures, and components.
• Pull chain control provides simple and reliable manual operation for raising and lowering loads.
• High rated lifting speed of 110 ft/min (33.5 m/min) improves productivity during repetitive material handling tasks.
• Compact pneumatic design delivers dependable operation using compressed air.
• Steel snap hook provides a secure attachment point for overhead lifting applications.
• Single-fall load chain configuration delivers efficient lifting performance for light-duty service.
• Compact, lightweight construction simplifies installation where overhead space is limited.
• Suitable for manufacturing, maintenance, assembly, and general industrial material handling applications.

Made in USA:

Applications:

• Assembly workstations handling lightweight parts and subassemblies.
• Manufacturing facilities requiring rapid overhead lifting and positioning.
• Maintenance operations lifting pumps, motors, valves, and replacement components.
• Machine shops positioning tooling, fixtures, and workpieces.
• General industrial material handling utilizing compressed-air lifting equipment.

FAQs:

• Q: What is the lifting capacity of this hoist?
  A: The 7770E model is rated for 275 lb (125 kg / 0.125 Metric Ton).
• Q: What type of control does this model use?
  A: This configuration uses a pull chain control, allowing the operator to manually actuate the hoist for raising and lowering loads.
• Q: What is the lifting height of this hoist?
  A: This model is supplied with a 10 ft lift for light-duty overhead material handling applications.
• Q: What industries commonly use this hoist?
  A: It is commonly used in manufacturing, assembly, maintenance, machine shops, and other industrial environments requiring compact pneumatic lifting equipment.

 Looking for more information about Ingersoll Rand Air Hoist? Click here to view the Catalog

Need more feet of chain or a longer pendant hose? How about a motorized trolley? Give us a call at 1-800-608-5210 or email info@intlairtool.com. We can help!
