Ingersoll Rand 24SR-207 Lock Clip

When maintaining a pneumatic chipping hammer's retainer assembly, identifying the correct locking component is important for proper reassembly. The Ingersoll Rand 24SR-207 Lock Clip is a manufacturer-listed replacement component used in the rubber-buffered retainer arrangement for Ingersoll Rand W Series chipping hammers. Identified in the Construction Tool Steels and Accessories catalog, this lock clip forms part of the HHW1-A300 rubber-buffered retainer assembly, a threaded retainer configuration listed as standard on W Series chippers. Its locking function supports the intended positioning and retention of the retainer's associated components during operation.

The 24SR-207 is identified separately from the upper buffer washer, lower buffer washer, lower buffer washer ring, and rubber bumper within the assembly. The manufacturer's catalog illustrates the clip as an open-ring component, allowing technicians to visually distinguish it from the surrounding washer and bumper parts. Its dedicated part number makes it easier to identify the appropriate replacement during retainer inspection, disassembly, and repair. Before ordering, confirm that the chipping hammer is equipped with the applicable HHW1-A300 retainer and verify the required component against the manufacturer's parts documentation.

Note: Other Ingersoll Rand Steels and accessories include Bushing Tools, Moil Points, Ground Rod Driver, Spark-Resistant Chisels, Flat Chisel, Blanks, Capes, Gouges, Round Noses, Fullers, Caulkings, Tooth Chisels, Paper Box Stripping Chisels, Jack Rods, Bits, Diamond Points, Clay Spades, Couplers, Cutters, Hoses, Lock Clips, Lock Springs, Rubber Bumpers, Shanks and Washer etc.

Type: Lock Clip | Part Number: 24SR-207 | Brand: Ingersoll Rand | Product Category: Chipping Hammer Accessories | Associated Retainer: HHW1-A300 | Retainer Configuration: Rubber-Buffered, Threaded | Associated Tool Series: W Series | Application: Chipping Hammer Retainer Maintenance

Features:

• Manufacturer-listed lock clip for replacement and maintenance of compatible chipping hammer retainer assemblies.
• Identified as a component of the HHW1-A300 rubber-buffered retainer arrangement.
• Locking component supports the intended retention of associated parts within the retainer assembly.
• Open-ring configuration is illustrated in the manufacturer's construction tool accessories catalog.
• Part number 24SR-207 enables accurate identification when ordering replacement retainer components.
• Separately cataloged from the buffer washers, washer ring, and rubber bumper to help technicians distinguish individual service parts.

Applications:

• Chipping hammer retainer servicing: Replacing a damaged or missing lock clip in the appropriate rubber-buffered retainer assembly.
• Construction tool maintenance: Supporting repair and reassembly of compatible Ingersoll Rand W Series chipping hammer retainers.
• Industrial pneumatic tool repair: Identifying and replacing locking components during retainer inspection and servicing.
• Tool crib and MRO inventory: Maintaining replacement lock clips for supported pneumatic chipping hammer assemblies.

FAQs:

• Q: What is the Ingersoll Rand 24SR-207 Lock Clip used for?

  A: The 24SR-207 is a locking component associated with the rubber-buffered chipping hammer retainer assembly. It is intended for use in the specified retainer arrangement rather than as a general-purpose retaining clip.

• Q: Which Ingersoll Rand retainer uses the 24SR-207 Lock Clip?

  A: The lock clip is listed as a component of the HHW1-A300 rubber-buffered retainer. This threaded retainer is identified as standard on Ingersoll Rand W Series chipping hammers. Confirm the actual retainer installed on the tool before ordering.

• Q: Is the 24SR-207 the same as the lock spring used with grooved retainers?

  A: No. The 24SR-207 is the lock clip associated with the rubber-buffered retainer arrangement. The HH1-1194 lock spring is separately identified for grooved retainers. These parts have different catalog designations and should not be assumed interchangeable.

• Q: Does the 24SR-207 include the complete retainer assembly?

  A: The 24SR-207 is listed as an individual lock clip component, not as the complete HHW1-A300 retainer assembly. The upper buffer washers, lower buffer washers, washer ring, and rubber bumper are identified under separate part numbers.
