Built for controlled cutting and trimming applications, the Dotco 14-2711 Saw Blade features a 4" diameter, 3/4" arbor hole, and 12 carbide-tipped teeth for fast, efficient material removal on compatible Dotco pneumatic saws. With a 1" maximum depth of cut, this replacement blade is well suited for operations where a lower tooth count provides quicker cutting through suitable materials while maintaining dependable performance.
Its carbide-tipped teeth (wear-resistant cutting inserts that retain their edge longer than conventional steel teeth) help reduce blade wear and maintain cutting efficiency during routine industrial use. The 12-tooth configuration is commonly preferred for applications that prioritize faster cutting over fine finish quality, making this blade an excellent choice for production, fabrication, and maintenance environments.
Type: Replacement Saw Blade | Blade Diameter: 4" | Arbor Hole: 3/4" | Tooth Style: Carbide Tip | Teeth: 12 | Maximum Depth of Cut: 1"
Features:
- Replacement blade for compatible Dotco pneumatic saws.
- 12 carbide-tipped teeth provide efficient cutting with extended edge retention.
- 4-inch blade diameter supports compact cutting and trimming applications.
- 3/4-inch arbor hole matches designated Dotco saw mounting configurations.
- Rated for a maximum cutting depth of 1 inch.
- Suitable for replacing worn or damaged blades during routine equipment maintenance.
Made in USA:
Applications:
- Composite trimming and fabrication operations requiring efficient material removal.
- Industrial production cutting where faster feed rates are preferred.
- Woodworking and panel cutting using compatible Dotco pneumatic saws.
- Maintenance departments replacing worn cutting blades on production equipment.
- General fabrication and repair work requiring a 4-inch carbide-tip saw blade.
FAQs:
- Q: What is the difference between the 12-tooth and 20-tooth Dotco blades?
A: The 12-tooth blade is generally better suited for faster cutting, while a 20-tooth blade typically produces a smoother finished cut. Always select the blade recommended for your application. - Q: What arbor size does this blade use?
A: The blade features a 3/4-inch arbor hole and should only be installed on compatible saws designed for this mounting size. - Q: What is the maximum cutting depth?
A: This blade is rated for a maximum depth of cut of 1 inch when installed on the appropriate compatible Dotco saw. - Q: Is this a replacement blade only?
A: Yes. The Dotco 14-2711 is supplied as a replacement saw blade and does not include the pneumatic saw.
| SKU | Description | Maximum Depth of Cut | Diameter |
|---|---|---|---|
| in | in | ||
| 14-2690 | 4“OD Diamond 60-80 Grit for Fiberglass, Composite, Carbon Fiber | 1“ x 5/64“ | 4 |
| 14-2700 | 4“OD Carbide Tip 20T for Thicker Fiberglass, Plastic Laminates to 1/2” thick | 1“ x 7/64“ | 4 |
| 14-2710 | 4“OD Carbide Tip 20T special for Thin non-ferrous material (to approx . 1/8” thick) | 1“ x 7/64“ | 4 |
| 14-2711 | 4“OD Carbide Tip 12T Special for Thicker non-ferrous material (to approx . 1/2” thick) | 1“ x 7/64“ | 4 |
Looking for more information about Dotco Saw Blade? Click here to view the Catalog.
Need help selecting the correct Dotco Saw Blades for your application? Please call (800) 608-5210 or email info@intlairtool.com
- Type
- Saw Blade
- Diameter (in.)
- 4
- Arbor Hole (in.)
- 3/4
- Teeth Count
- Carbide Tip 12 Teeth
- Max Depth of Cut (in.)
- 1
- Max Width of Cut (in.)
- 7/64
