Coxreels EZ-TSHL-550-BBX DEF Supreme Duty Spring Rewind Hose Reel | DEF-T Series | 3/4" Hose Diameter | 50' Hose Length | 300 Max PSI | Less Hose

Built for Diesel Exhaust Fluid dispensing setups on shop floors, service trucks, fleet maintenance areas, and mobile equipment skids, the Coxreels EZ-TSHL-550-BBX DEF Supreme Duty Spring Rewind Hose Reel provides organized hose storage for 3/4" I.D. hose with a 50 ft hose capacity and 300 PSI maximum pressure rating. As part of the DEF-T Series, this EZ-Coil reel uses Coxreels' controlled rewind system, which slows hose retraction compared with conventional spring reels to help reduce whip, improve handling, and keep DEF dispensing areas cleaner and safer.

The supreme-duty dual pedestal T Series configuration is built around a wide steel chassis, Super Hub triple axle support system, stainless steel DEF swivel, and Viton swivel seals for compatibility with Diesel Exhaust Fluid handling. The spring rewind mechanism stores the hose after use, while the multi-position guide arm supports wall, floor, vehicle, ceiling, and overhead mounting layouts where installation space and hose payout direction matter.

*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.

Type: DEF Spring Rewind Hose Reel | Series: DEF-T Series / EZ-Coil Specialty Reels | Model: EZ-TSHL-550-BBX | Configuration: Less Hose | Hose I.D.: 3/4" | Hose O.D.: 1 1/8" | Hose Capacity: 50 ft | Max Pressure: 300 PSI | Hose Included: No | Swivel: Stainless Steel 90° Full-Flow NPT | Swivel Seals: Viton | Overall Dimensions: 9.38" W x 25.5" H x 24" L | Mounting Pattern: 7" M x 8" N | Base: 8" X x 9" Y | Ship Weight: 70 lbs

Features:

• EZ-Coil controlled rewind system retracts up to 80% slower than conventional reels for more controlled hose return.
• Stainless steel 90° full-flow NPT swivel supports Diesel Exhaust Fluid dispensing and provides an accessible external fluid path for seal maintenance and hose installation.
• Viton swivel seals provide chemical resistance for DEF service.
• Supreme-duty dual pedestal T Series frame uses Coxreels’ Super Hub triple axle support system to improve stability and reduce vibration during operation.
• Solid one-piece 1/4" steel base and support posts add strength for stationary and rugged mobile mounting environments.
• 1" solid steel axle with lubricated precision bearings promotes smooth drum rotation during hose payout and rewind.
• Multi-position guide arm adjusts for wall, floor, vehicle, ceiling, and overhead mounting positions.
• CPC powder coat finish helps resist chips and rust in shop, fleet, and service-truck environments.

Made in USA:

2 Year Warranty

Applications:

• Fleet maintenance facilities - managing DEF dispensing hose for trucks, buses, and off-road diesel equipment.
• Service trucks and mobile lube skids - storing DEF hose securely while supporting field fueling and fluid service routes.
• Truck shops and diesel repair bays - keeping 50 ft of DEF dispensing hose organized and off the floor between fills.
• Equipment yards and municipal garages - supporting controlled DEF transfer where hose reach and clean storage matter.
• Agricultural and construction maintenance areas - providing a rewind reel solution for DEF handling around tractors, loaders, generators, and diesel-powered machinery.

FAQs:

• Q: What does less hose mean on the EZ-TSHL-550-BBX?
  A: It means this reel is supplied without hose installed. The buyer must provide a compatible 3/4" I.D. DEF dispensing hose separately.
• Q: Is this reel made specifically for Diesel Exhaust Fluid?
  A: Yes. The DEF-T Series uses a stainless steel external full-flow swivel and Viton seals for Diesel Exhaust Fluid dispensing service.
• Q: What is the benefit of EZ-Coil controlled rewind?
  A: EZ-Coil slows the rewind speed compared with standard spring reels, helping the hose return in a more controlled way after use.
• Q: Can this reel be mounted on a service truck?
  A: Yes. The guide arm can be positioned for vehicle mounting, and the dual pedestal T Series frame is suited for stationary or rugged mobile applications when installed correctly.
• Q: What hose size should be used with this reel?
  A: This model is listed for 3/4" I.D. hose with a 50 ft capacity and 300 PSI maximum pressure rating. Confirm the selected DEF hose outside diameter, fittings, and pressure rating before installation.

Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.

For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
