Coxreels EZ-TSHL-450-BBX DEF Supreme Duty Spring Rewind Hose Reel | DEF-T Series | 1/2" Hose Diameter | 50' Hose Length | 300 Max PSI | Less Hose

Built for Diesel Exhaust Fluid dispensing layouts where controlled hose return and DEF-compatible wetted components matter, the Coxreels EZ-TSHL-450-BBX is a DEF-T Series supreme duty spring rewind reel supplied less hose. This reel is configured for 1/2" I.D. DEF hose with a listed 50 ft hose capacity and 300 PSI maximum pressure rating, giving maintenance shops, fueling stations, and mobile service units a clean way to manage DEF transfer hose without leaving excess hose on the floor or vehicle deck.

The DEF-T Series uses a dual pedestal configuration for added reel support, while the EZ-Coil safety system provides controlled retraction, meaning the hose rewinds more slowly and with less snap-back than a conventional spring rewind reel. DEF, or Diesel Exhaust Fluid, requires compatible materials because contamination can affect SCR system performance; this reel family uses a stainless steel external full-flow swivel and Viton seals for DEF dispensing service.

*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.

Type: Spring Rewind DEF Hose Reel | Series: DEF-T Series | Model: EZ-TSHL-450-BBX | Configuration: Less Hose | Retraction: EZ-Coil Safety System | Hose I.D.: 1/2" | Hose Capacity: 50 ft | Max Pressure: 300 PSI | Ship Weight: 55 lbs | Overall Dimensions: 9-3/8" W x 21-1/4" H x 19-1/2" L | Base: 8" x 9" | Mounting Pattern: 7" x 8"

Features:

• EZ-Coil controlled retraction helps reduce rewind speed for safer, more manageable hose return compared with standard spring rewind reels.
• DEF-compatible stainless steel 90° external full-flow NPT swivel supports Diesel Exhaust Fluid dispensing applications.
• Viton swivel seals provide chemical resistance for DEF service.
• Dual pedestal DEF-T Series frame provides added reel support for stationary installations and mobile fueling equipment.
• Coxreels' Super Hub triple axle support system helps increase stability and reduce vibration during reel operation.
• Guide arm adjusts for wall, floor, vehicle, and overhead mounting positions, helping the reel fit the available dispensing layout.
• Solid one-piece heavy gauge steel base and support posts with a 1" solid steel axle and lubricated precision bearings support smooth rotation.
• Rolled edges and ribbed discs add strength and help protect the reel structure during day-to-day use.

Made in USA:

2 Year Warranty

Applications:

• DEF storage and dispensing systems where a bare reel is preferred for installing a separately sourced compatible DEF hose.
• Fleet maintenance shops managing Diesel Exhaust Fluid hose around service bays, tote systems, or fixed dispensing stations.
• Fuel and lube trucks that need a spring rewind reel for organizing DEF hose during mobile equipment service.
• Truck maintenance facilities and diesel service operations where hose control helps reduce floor clutter and trip hazards.
• Stationary or vehicle-mounted DEF transfer setups requiring a 300 PSI low-pressure reel with DEF-compatible swivel components.

FAQs:

• Q: What does less hose mean on this Coxreels DEF reel?
  A: Less hose means the reel is supplied without hose installed. The buyer must provide a compatible DEF dispensing hose separately, within the reel's listed 1/2" I.D., 3/4" maximum O.D., and 50 ft capacity.
• Q: What is EZ-Coil retraction?
  A: EZ-Coil is Coxreels' controlled retraction system. It slows the rewind action compared with conventional spring rewind reels, helping reduce hose whip and making rewind more manageable for the operator.
• Q: Can this reel be used for Diesel Exhaust Fluid?
  A: Yes. The DEF Series is built for DEF dispensing service and uses a stainless steel external full-flow swivel with Viton seals. Always pair the reel with hose and fittings that are also compatible with DEF.
• Q: What mounting options does the guide arm support?
  A: The guide arm can be adjusted for wall, floor, vehicle, and overhead positions. Confirm available clearance against the reel's 9-3/8" W x 21-1/4" H x 19-1/2" L overall dimensions before installation.

Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.

For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
