Coxreels EZ-SHL-525-BBX DEF Heavy Duty Spring Rewind Hose Reel | DEF-SH Series | 3/4" Hose Diameter | 25' Hose Length | 300 Max PSI | Less Hose

Built for higher-flow Diesel Exhaust Fluid dispensing in fleet shops, mobile service vehicles, tank trucks, and DEF storage systems, the Coxreels EZ-SHL-525-BBX DEF Heavy Duty Spring Rewind Hose Reel provides organized hose handling for 3/4" I.D. DEF transfer hose up to 25 ft. The 300 PSI pressure rating supports low-pressure DEF dispensing layouts, while the DEF-SH single pedestal frame gives installers a compact reel platform for wall, floor, vehicle, or overhead mounting.

This DEF Series reel is built around DEF-compatible fluid path components, including a stainless steel external full-flow swivel and chemical-resistant Viton seals. Diesel Exhaust Fluid (DEF) is a high-purity aqueous urea solution used in selective catalytic reduction systems, so material compatibility is important when selecting reels, hoses, and fittings. The EZ-Coil spring rewind system controls retraction speed to help reduce hose whip and improve handling during daily dispensing work.

*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.

Type: Spring Rewind DEF Hose Reel | Series: DEF-SH Series | Configuration: Less Hose | Model: EZ-SHL-525-BBX | Hose I.D.: 3/4" | Hose O.D. Capacity: 1-1/8" | Hose Capacity: 25 ft | Max Pressure: 300 PSI | Approx. Ship Weight: 45 lbs | Size Index: 3

Features:

• Stainless steel 90° full-flow NPT swivel supports DEF dispensing and provides direct access for seal maintenance.
• Viton swivel seals provide chemical resistance for Diesel Exhaust Fluid service.
• EZ-Coil controlled-retraction system rewinds up to 80% slower than conventional spring-driven reels for safer hose return.
• Single pedestal DEF-SH construction keeps the reel compact while supporting 3/4" I.D. hose storage.
• Adjustable guide arm allows wall, floor, vehicle, and overhead mounting to match shop or truck installation requirements.
• Super Hub dual axle support system increases stability during hose pullout and rewind.
• Heavy-gauge steel base, 1" solid steel axle, and lubricated precision bearings support smooth reel rotation.
• CPC powder coat finish, rolled edges, and ribbed discs help protect the reel structure in work environments where DEF equipment is used daily.

Made in USA:

2 Year Warranty

Applications:

• Fleet maintenance shops dispensing DEF into diesel trucks, buses, and service vehicles.
• Mobile lube and fuel service trucks where a compact spring rewind reel helps keep hose stored between stops.
• DEF storage tanks and transfer stations using customer-selected hose for a specific dispensing setup.
• Truck dealerships and diesel repair facilities needing organized 3/4" hose management for DEF handling.
• Tank truck and shop layouts where stainless steel swivel construction and Viton seals are required for DEF compatibility.

FAQs:

• Q: What does less hose mean for the EZ-SHL-525-BBX?
  A: It means this reel is supplied without hose installed. The buyer must provide compatible DEF hose separately, matching the reel’s 3/4" I.D., 1-1/8" O.D. capacity, 25 ft hose capacity, and 300 PSI pressure rating.
• Q: Is this reel made specifically for Diesel Exhaust Fluid?
  A: Yes. The DEF Series configuration uses a stainless steel external full-flow swivel and Viton seals for DEF dispensing applications.
• Q: Why choose the 3/4" x 25 ft version instead of a 1/2" reel?
  A: A 3/4" hose size is commonly selected when the dispensing setup requires a larger flow path than 1/2" hose. The 25 ft capacity works well when the reel is mounted close to the DEF tank, pump, or dispensing point.
• Q: Can this reel be mounted on a service truck?
  A: Yes, the adjustable guide arm supports vehicle mounting as well as wall, floor, and overhead mounting. Confirm the mounting surface, bolt pattern, and hose routing before installation.
• Q: What does EZ-Coil do?
  A: EZ-Coil slows the rewind speed compared with standard spring-driven reels. This helps improve hose control and reduce sudden snap-back during retraction.
