Coxreels EZ-SHL-450-BBX DEF Heavy Duty Spring Rewind Hose Reel | DEF-SH Series | 1/2" Hose Diameter | 50' Hose Length | 300 Max PSI | Less Hose

Built for diesel exhaust fluid handling in service shops, fleet facilities, tank trucks, fuel/lube trucks, and DEF storage or dispensing systems, the Coxreels EZ-SHL-450-BBX DEF Heavy Duty Spring Rewind Hose Reel provides controlled hose payout and rewind for 1/2" I.D. DEF transfer hose up to 50 ft. Its 300 PSI pressure rating supports low-pressure DEF dispensing layouts, while the DEF-SH single pedestal configuration keeps the reel compact enough for wall, floor, vehicle, or overhead mounting.

This DEF Series reel uses a stainless steel external full-flow swivel and chemical-resistant Viton seals to help protect Diesel Exhaust Fluid (DEF), a high-purity aqueous urea solution used in diesel emissions systems. The EZ-Coil spring rewind system slows retraction compared with conventional spring reels, helping reduce hose whip and improving control during daily dispensing work.

*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.

Type: Spring Rewind DEF Hose Reel | Series: DEF-SH Series | Configuration: Less Hose | Model: EZ-SHL-450-BBX | Hose I.D.: 1/2" | Hose O.D. Capacity: 7/8" | Hose Capacity: 50 ft | Max Pressure: 300 PSI | Approx. Ship Weight: 46 lbs | Size Index: 1

Features:

• Stainless steel 90° full-flow NPT swivel is built for Diesel Exhaust Fluid dispensing applications and helps simplify seal access during maintenance.
• Viton swivel seals provide chemical resistance for DEF service.
• EZ-Coil safety system retracts up to 80% slower than conventional spring-driven reels for better hose control.
• Sturdy single pedestal reel includes Coxreels’ Super Hub dual axle support system to improve stability and reduce vibration during operation.
• Guide arm adjusts for wall, floor, vehicle, and overhead mounting positions.
• Solid one-piece, heavy-gauge 1/4" steel base and support post help keep the reel stable during pullout and rewind.
• 1" solid steel axle and lubricated precision bearings support smooth rotation.
• Rolled edges, ribbed discs, and CPC™ powder coat finish support hose protection and corrosion-resistant reel construction.

Made in USA:

2 Year Warranty

Applications:

• DEF storage and dispensing systems where a less-hose reel is needed for a customer-specified DEF hose.
• Fleet and truck maintenance facilities handling Diesel Exhaust Fluid for SCR-equipped diesel vehicles.
• Fuel/lube trucks and mobile service vehicles requiring compact spring rewind hose storage.
• Tank truck and shop dispensing layouts where controlled hose retraction helps keep work areas organized.
• Stationary DEF transfer stations where stainless steel swivel construction and Viton® seals are required for fluid compatibility.

FAQs:

• Q: What does less hose mean on the EZ-SHL-450-BBX?
  A: It means the reel is supplied without hose installed. The buyer must provide compatible DEF dispensing hose separately, matching the reel’s 1/2" I.D., 7/8" O.D. capacity, 50 ft hose capacity, and 300 PSI pressure rating.
• Q: Is this reel suitable for Diesel Exhaust Fluid?
  A: Yes. The DEF Series configuration includes a stainless steel external full-flow swivel and Viton seals for DEF dispensing applications.
• Q: Where can this reel be mounted?
  A: The adjustable guide arm allows wall, floor, vehicle, and overhead mounting positions, as long as the mounting surface and bolt pattern are appropriate for the reel’s size and loaded use.
• Q: What is the benefit of the EZ-Coil rewind system?
  A: EZ-Coil controls retraction speed up to 80% slower than conventional spring-driven reels, helping reduce sudden hose snap-back during rewind.
• Q: Can this reel be used with any 1/2" hose?
  A: Use hose that is compatible with DEF and does not exceed the reel’s listed hose O.D. capacity. Confirm hose pressure rating, length, and fluid compatibility before installation.

Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.

For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
