The Chicago Pneumatic CP7737 Impact Wrench delivers smooth operation and extended durability. It is a versatile tool ideal for all general repairs and maintenance applications. It features composite cover, jumbo hammer mechanism, steel motor and direct drive transmission mechanism for improved performance and strength. The single hand reverse/forward operation offers 3 positions in forward and 1 in reverse with full teasing trigger and socket retainer ring gives the operator convenient control of the forward/reverse power. Over molded composite and ergonomic handle fits perfectly in hand and offers a durable and comfortable grip. With 221 ft. lbs – 300 Nm of maximum torque in reverse, this impact wrench provides full power, and a working torque range of 25.1 to 165 ft./lbs. This product weighs 2.5 lbs, measures 9.45 inches long, and has a 1/2-inch square drive.
Type: Impact Wrench | Drive Size (in.): 1/2 | Impact Mecanism: Single hammer | Blows Per Minute (BPM): 1600 | Free Speed (RPM): 9000 | Working Torque Range (ft-lbs): 25.1-165 | Working Torque Range (fwd) (Nm): 34-224 | Max Reverse Torque (ft-lbs): 221 | Max Reverse Torque (Nm): 300 | Length (in.): 9.45 | Length (mm): 240 | Air Consumption @ Load (CFM): 16 | Air Consumption @ Load (l/s): 7.5 | Vibration Level (a): 10.3 | Vibration Level (k): 1.3 | Sound Pressure (dbA): 93 | Sound Power (dbA): 104 | Air Inlet Size (in.): 1/4 | Min Hose Size (in.): 3/8 | Min Hose Size (mm): 10
Features:
- Jumbo hammer mechanism
- Steel motor
- Composite cover
- Direct drive transmission mechanism
- 9.4 in -240 mm length & 3.46 in. (88 mm) height
- Over molded composite and ergonomic handle to fit perfectly in hand
- Full teasing trigger
- Single handed Forward – Reverse operation
- 3 positions in forward and 1 in reverse
- Socket retainer ring
Benefits:
- High Durability
- Compact
- Powerful
- Comfort
- Great Control
- Easy Operation
- Single handed Forward – Reverse operation
- 3 positions in forward and 1 in reverse
Looking for more information about Chicago Pneumatic Grinder? Click here to view the Catalog.
For help selecting the correct Chicago Pneumatic Grinders for your assembly application, call (800) 608-5210 or email info@intlairtool.com
- Type
- Impact Wrench
- Drive Size (in.)
- 1/2
- Impact Mechanism
- Single hammer
- Blows Per Minute (BPM)
- 1600
- RPM
- 9000
- Working Torque Range (ft-lbs)
- 25.1-165
- Working Torque Range (fwd) (nm)
- 34-224
- Max Reverse Torque (ft-lbs)
- 221
- Max Reverse Torque (nm)
- 300
- Length (in.)
- 9.45
- Length (mm)
- 240
- Air Consumption @ Load (CFM)
- 16
- Air Consumption @ Load (l/s)
- 7.5
- Vibration Level (a)
- 10.3
- Vibration Level (k)
- 1.3
- Sound Pressure (dbA)
- 93
- Sound Power (dbA)
- 104
- Air Inlet
- 1/4" NPT
- Min Hose Size (in.)
- 3/8
- Min Hose Size (mm)
- 10
