Designed for tire service applications, the Chicago Pneumatic CP8323 Cordless Tire Buffer Bare Tool provides a 2,500 RPM free speed and accepts accessories through a 7/16" chuck. The specified battery capacity is 2 Ah, while the bare tool has a 1.96 lb net weight and 9.88" length. This configuration is supplied as the bare tool, with the battery not included.
The CP8323 Cordless Tire Buffer Bare Tool is identified by part number 8941083230. The manufacturer table specifies a 7/16" (11 mm) maximum chuck capacity, 1.96 lb weight without battery, vibration values of 10.6 m/s² with a 4.9 m/s² uncertainty value, sound pressure of 66.4 dB(A), and sound power of 77.4 dB(A).
Type: Cordless Tire Buffer | Model: CP8323 CORDLESS TIRE BUFFER BARE TOOL | Part Number: 8941083230 | Battery Capacity: 2 Ah | Chuck Max Capacity: 7/16" (11 mm) | Free Speed: 2,500 RPM | Net Weight: 1.96 lb | Length: 9.88" | Weight Without Battery: 1.96 lb | Vibration Level: 10.6 m/s² | Vibration Uncertainty: 4.9 m/s² | Sound Pressure: 66.4 dB(A) | Sound Power: 77.4 dB(A)
Features:
- 2,500 RPM free speed provides the specified operating speed for tire buffing applications.
- 7/16" maximum chuck capacity accommodates compatible accessories up to the specified size.
- 11 mm maximum chuck capacity is the metric equivalent listed in the manufacturer table.
- 2 Ah battery capacity identifies the specified battery configuration.
- 1.96 lb net weight keeps the bare-tool configuration at the listed weight.
- 9.88" overall length provides the manufacturer's specified tool length.
- Weight without battery is listed as 1.96 lb, or 0.9 kg.
- Vibration is specified at 10.6 m/s² with a 4.9 m/s² uncertainty value according to ISO 28927.
- Sound pressure is listed at 66.4 dB(A) according to ISO 15744.
- Sound power is listed at 77.4 dB(A).
Applications:
- Tire buffing and preparation applications using compatible accessories.
- Tire repair and service work requiring a cordless buffer configuration.
- Applications requiring a maximum chuck capacity of 7/16" (11 mm).
- Tire service tasks where the specified 2,500 RPM free speed is appropriate.
FAQs:
- Q: What is the free speed of the CP8323?
A: The manufacturer table specifies a free speed of 2,500 RPM. - Q: What is the maximum chuck capacity?
A: The maximum chuck capacity is 7/16", also listed as 11 mm. - Q: What is the battery capacity listed for the CP8323?
A: The manufacturer table lists a battery capacity of 2 Ah. - Q: What is the weight of the bare tool?
A: The net weight is 1.96 lb, and the weight without battery is also listed as 1.96 lb. - Q: What is the length of the CP8323 Bare Tool?
A: The specified length is 9.88", or 251 mm. - Q: What are the vibration specifications?
A: The table lists a vibration level of 10.6 m/s² and an uncertainty value of 4.9 m/s² under ISO 28927. - Q: What are the sound specifications?
A: The listed sound pressure is 66.4 dB(A), while sound power is 77.4 dB(A).
| Model | Part Number | Battery Capacity (Ah) |
Chuck Max Capacity (in.) |
Chuck Max Capacity (mm) |
Free Speed (rpm) |
Net Weight (lb) |
Net Weight (kg) |
Length (in.) |
Length (mm) |
Weight Without Battery (lb) |
Weight Without Battery (kg) |
Vibration (ft/s²) |
Vibration Uncertainty (ft/s²) |
Sound Pressure dB(A) |
Sound Power dB(A) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ModelCP8323 CORDLESS TIRE BUFFER KIT | Part Number8941183230 | Battery Capacity (Ah)2 | Chuck Max Capacity (in.)7/16 | Chuck Max Capacity (mm)11 | Free Speed (rpm)2500 | Net Weight (lb)2.62 | Net Weight (kg)1.19 | Length (in.)12.09 | Length (mm)307 | Weight Without Battery (lb)1.96 | Weight Without Battery (kg)0.9 | Vibration (ft/s²)10.6 | Vibration Uncertainty (ft/s²)4.9 | Sound Pressure dB(A)66.4 | Sound Power dB(A)77.4 |
| ModelCP8323 CORDLESS TIRE BUFFER BARE TOOL | Part Number8941083230 | Battery Capacity (Ah)2 | Chuck Max Capacity (in.)7/16 | Chuck Max Capacity (mm)11 | Free Speed (rpm)2500 | Net Weight (lb)1.96 | Net Weight (kg)0.9 | Length (in.)9.88 | Length (mm)251 | Weight Without Battery (lb)1.96 | Weight Without Battery (kg)0.9 | Vibration (ft/s²)10.6 | Vibration Uncertainty (ft/s²)4.9 | Sound Pressure dB(A)66.4 | Sound Power dB(A)77.4 |
| ModelCP8323 CORDLESS TIRE BUFFER KIT NA VERSION | Part Number8941283230 | Battery Capacity (Ah)2 | Chuck Max Capacity (in.)7/16 | Chuck Max Capacity (mm)11 | Free Speed (rpm)2500 | Net Weight (lb)2.62 | Net Weight (kg)1.19 | Length (in.)12.09 | Length (mm)307 | Weight Without Battery (lb)1.96 | Weight Without Battery (kg)0.9 | Vibration (ft/s²)10.6 | Vibration Uncertainty (ft/s²)4.9 | Sound Pressure dB(A)66.4 | Sound Power dB(A)77.4 |
Looking for more information about Chicago Pneumatic Tire Buffer For help selecting the correct Chicago Pneumatic Tire Buffer Bare Tools for your assembly application, call (800) 608-5210 or email info@intlairtool.com
- Type
- Cordless Buffer
- Handle Type
- Straight
- Chuck Capacity (in.)
- 7/16
- RPM
- 2500
- Sound Pressure (dBA)
- 66.4
- Sound Power (dBA)
- 77.4
