Dotco 10L1001-36 Inline Grinder | 10-10 Series | 0.3 HP | 34,000 RPM | 1/4" Collet | Aluminum Housing | Front Exhaust

Built for fast deburring, die/mold cleanup, and small-part finishing, the Dotco 10L1001-36 Inline Grinder combines a compact 10-10 Series body with 0.3 HP power for controlled material removal in tight work areas. Its 34,000 RPM free speed (no-load operating speed) supports quick cutting action with compatible carbide burrs and mounted wheels, while the 1/4 in. collet holds common shank accessories used in toolrooms, fabrication benches, and production finishing stations.

The front exhaust configuration directs spent air forward from the tool, and the lock-off lever throttle helps reduce accidental start-up by requiring deliberate lever engagement. With a 4.6 in. length and 0.66 lb tool weight, this aluminum-housing grinder gives technicians a compact inline option for edge breaking, burr removal, and detail grinding where larger die grinders may be harder to control.

Type: Inline Die Grinder | Series: 10-10 Series | Model: 10L1001-36 | Power: 0.3 HP / 0.22 kW | Free Speed: 34,000 RPM | Collet Size: 1/4 in. | Exhaust: Front | Throttle Type: Lock-Off Lever Throttle | Abrasive Capacity: 1/2 in. Carbide Burr, 1 in. Mounted Wheel | Housing Material: Aluminum | Weight: 0.66 lb | Length: 4.6 in. / 117 mm | Air Inlet: 1/4 in. NPT | Minimum Hose I.D.: 1/4 in. / 6.4 mm | Rated Air Pressure: 90 PSI / 620 kPa

Features:

• Durable aluminum housing supports frequent use in die/mold work, deburring, and precision finishing.
• Compact inline body improves control and access when working around small features, edges, cavities, and close-clearance parts.
• Lock-off lever throttle helps prevent accidental start-up during handling or repositioning.
• Front exhaust configuration routes air forward from the tool body for this specific model setup.
• 34,000 RPM speed selection supports fast material removal with properly rated carbide burrs and mounted wheels.
• Rated abrasive capacity includes 1/2 in. carbide burrs and 1 in. mounted wheels.
• Standard equipment includes the applicable collet and collet wrenches for setup and accessory changes.

Made in USA:

Applications:

• Die and mold work — cleaning flash, refining small contours, and finishing details with compatible carbide burrs.
• Metal fabrication — removing burrs from cut edges, holes, slots, and machined features after drilling, milling, or sawing.
• Industrial maintenance and MRO — touch-up grinding on brackets, fixtures, guards, and small repair parts.
• Aerospace and precision manufacturing — controlled detail finishing where a compact inline grinder is easier to guide than a larger tool.
• Toolroom and bench work — everyday edge breaking, porting, and mounted-wheel cleanup tasks on steel, aluminum, and similar materials.

FAQs:

• Q: What is the Dotco 10L1001-36 used for?
  A: It is used for inline die grinding, deburring, die/mold cleanup, and small-area finishing. Its compact size and 34,000 RPM speed make it useful for detail work where a larger grinder may be difficult to control.
• Q: What accessories fit the 1/4 in. collet?
  A: The grinder accepts compatible 1/4 in. shank accessories and is rated for 1/2 in. carbide burrs and 1 in. mounted wheels. Always verify both the shank size and maximum RPM rating before mounting an accessory.
• Q: What does lock-off lever throttle mean?
  A: A lock-off lever throttle requires an intentional action before the lever can start the tool. This helps reduce accidental start-up during handling, positioning, or accessory changes.
• Q: How does front exhaust affect use?
  A: Front exhaust routes spent air forward from the tool body. This may be acceptable for many bench and production tasks, but buyers who prefer air directed away from the work area may want to compare rear exhaust models in the same Dotco 10-10 Series.
• Q: Can this grinder be used with any abrasive accessory rated for 1/4 in. shanks?
  A: No. The accessory must fit the collet, match the tool’s abrasive capacity, and have a maximum operating speed equal to or higher than 34,000 RPM.
