Chicago Pneumatic CP7782 Impact Wrench | 1" Drive | 1920 (ft.-lb.) Max Torque | 5200 RPM

Product images may not be an exact representation of the actual product. Please check the description below for technical specifications.

Chicago Pneumatic

Chicago Pneumatic CP7782 Impact Wrench | 1" Drive | Max Torque 1920 Ft. Lbs. | 5200 RPM

List Price: $1,415.40
$849.24
(You save $566.16 )
Availability:
Usually Ships Within 2 to 4 Business Days | Contact Customer Service for Details
SKU:
8941077820
Shipping:
Calculated at Checkout
Weight:
22.20 LBS
Condition:
New
UPC:
8941077820
Adding to cart… The item has been added
Description


The Chicago Pneumatic CP7782 Impact Wrench delivers easy operation and extended durability. It is a Durable impact wrench with great power for the toughest jobs on heavy vehicles. It has a high efficiency motor, yet it is economical with durable reinforced clutch mechanism. It features pinless closed reinforced rocking dog impact mechanism for improved performance. It is a 1" straight impact wrench with 1" short anvil. The Regulator is integrated with forward/reverse with 3-position power settings in both directions. It also has dual socket retention, hole and friction ring. The ergonomic side handle offers a durable and comfortable grip and superior operator comfort. With 1920 ft. lbs - 2600 Nm of maximum torque in reverse, this impact wrench provides full power, and a working torque range of 369 to 1480 ft./lbs. This product weighs 22.2 lbs, measures 14.57 inches long, and has a 1-inch output drive.

Type: Impact Wrench | Drive Size (in.): 1 | Impact Mecanism: Pinless rocking dog | Blows Per Minute (BPM): 500 | Free Speed (RPM): 5200 | Working Torque Range (ft-lbs): 369-1,480 | Working Torque Range (fwd) (Nm): 500-2000 | Max Reverse Torque (ft-lbs): 1920 | Max Reverse Torque (Nm): 2600 | Length (in.): 14.57 | Length (mm): 370 | Air Consumption @ Load (CFM): 40.7 | Air Consumption @ Load (l/s): 19.2 | Vibration Level (a): 7.8 | Vibration Level (k): 1.8 | Sound Pressure (dbA): 100 | Sound Power (dbA): 111 | Air Inlet Size (in.): 1/2 | Min Hose Size (in.): 3/8 | Min Hose Size (mm): 10

Features:

  • 1" D-handle impact wrench with dual retainer (Hole + Ring)
  • Pinless closed reinforced rocking dog impact mechanism
  • ergonomic side handle
  • Integrated protective cover on the clutch housing
  • Full teasing trigger
  • Regulator with integrated forward/reverse with 3-position power settings in both directions

Benefits:

  • Great power for general maintenance applications
  • Reinforced clutch mechanism
  • Low vibration for better operator comfort

industrial-tools-parts-breakdown.pngLooking for more information about Chicago Pneumatic Grinder? Click here to view the Catalog.

For help selecting the correct Chicago Pneumatic Grinders for your assembly application, call (800) 608-5210 or email info@intlairtool.com

Specifications
Type:
Impact Wrench
Drive Size (in.):
1
Impact Mecanism:
Pinless rocking dog
Blows Per Minute (BPM):
500
Free Speed (RPM):
5200
Working Torque Range (ft-lbs):
369-1,480
Working Torque Range (fwd) (Nm):
500-2000
Max Reverse Torque (ft-lbs):
1920
Max Reverse Torque (Nm):
2600
Length (in.):
14.57
Length (mm):
370
Air Consumption @ Load (CFM):
40.7
Air Consumption @ Load (l/s):
19.2
Vibration Level (a):
7.8
Vibration Level (k):
1.8
Sound Pressure (dbA):
100
Sound Power (dbA):
111
Air Inlet Size (in.):
1/2
Min Hose Size (in.):
3/8
Min Hose Size (mm):
10
Warranty Information
One year warranty against defects in materials and workmanship
