Chicago Pneumatic CP717 Heavy Duty Pistol Grip Hammer is a powerful air tool built for demanding metalworking, repair, and fabrication tasks where high impact force is essential. Its 0.402" round shank ensures secure chisel retention and compatibility with heavy-duty accessories for tough applications. Delivering 1,800 BPM, it provides strong, controlled blows that make it ideal for cutting bolts, driving large rivets, and performing heavy chipping work. A robust 0.75" bore enhances impact energy, enabling efficient material removal even under continuous use. The 2.68" stroke offers deep, forceful strikes suited for thick metals and stubborn components. Designed with an ergonomic pistol grip, it improves operator control and reduces fatigue during extended operation. Durable, reliable, and built for industrial performance, the CP717 is a top choice for automotive, construction, and heavy-repair environments.
Type: Pistol Grip Hammer | Free Speed (RPM): 1800 | Length (in.): 7.48 | Length (mm): 190 | Air Consumption @ Load (CFM): 12 | Air Consumption @ Load (l/s): 5.9 | Vibration Level (a): 8.6 | Vibration Level (k): 28.2 | Sound Power (dbA): 106 | Air Inlet Size (in.): 1/4 | Bore (in.): 0.75 | Bore (mm): 19 | Stroke (in.): 2.68 | Stroke (mm): 68 | Min Hose Size (in.): 3/8 | Min Hose Size (mm): 10 | Shank (in.): 0.402 | Shank (mm): 12.7
Features & Benefits:
- Power and precision
- Flexible operating positions
- Ideal tool for deep cutting, bolt riveting, and super-duty applications
- Heavy-duty pistol-grip hammer
- High-power air hammer
- Positive action trigger
Looking for more information about Chicago Pneumatic Hammer? Click here to view the Catalog.
For help selecting the correct Chicago Pneumatic Hammers for your assembly application, call (800) 608-5210 or email info@intlairtool.com
