Allegro 9525-50EX 20" Axial Explosion-Proof High Output Metal Blower | 1.5 HP | 115V/208V-230V AC

Allegro 9525-50EX 20" Axial Explosion-Proof High Output Metal Blower | 1.5 HP | 115V/208V-230V AC | Safe, High-Performance Ventilation in Hazardous Locations

Engineered for the most demanding industrial environments, the Allegro 9525-50EX Explosion-Proof High Output Blower combines high-volume airflow with hazard-rated safety. With a powerful 1.5 HP explosion-proof motor, this 20-inch axial blower delivers maximum air movement while meeting strict NEC safety standards-making it ideal for confined spaces where flammable vapors, gases, or dust are present. The rugged, spark-resistant construction and dual-voltage capability (115V/208V-230V AC) make it versatile and dependable across a wide range of job sites-from oil refineries and chemical plants to shipyards and tanks.

When safety and performance can't be compromised, trust the Allegro 9525-50EX to keep your crew protected and your worksite ventilated.

Type: Axial Blower | Motor (HP): 1-1/2 | CFM: 6468 | CFM One 90° Bend: 4314 | CFM Two 90° Bend: 3922 | Electrical Current: 115V/208V-230V AC, 60 Hz | Configuration: EX | Housing: Metal | Design: Axial | Blower Phase: Single | Diameter (in.): 20

Features:

• 1-1/2 HP
• Available in both US and International wiring configurations
• Epoxy powder-coated in "safety orange"
• UL Recognized, CSA Certified
• 16-gauge cold rolled steel housing
• Integrated carrying handles
• Meets Class I, Division 1 and 2, Groups C & D, Class II Division 1 and 2 Groups F & G.
• Interchangeable flange
• Anti-Static glass reinforced polyamide (PAGAS) three blade fan with aluminum hub
• Made in USA
• Interchangeable flange for intake or exhaust side mounting
• Blower delivers high output for drawing or pushing air for added worker convenience
• Integrated carry handles for easy transport to work site
• The durable and tough metal housing can withstand the harshest of work conditions

Application:

• Construction
• Industrial
• Manufacturing
• Confined Space

Looking for more information about Walter Axial Blowers? Click here to view the Catalog

For help choosing the correct Walter Surface Technologies Axial Blower for your application, please call (800) 608-5210 or email info@intlairtool.com
